ex. VAT, ex. delivery costs
Brush electrode, for measuring in bores for PCE-PMI 4
Two needles 120 mm long
Variable distance
Brushes 40 mm long
7 mm diameter
Cable 920 mm long
of which 460 mm divided
3.5 mm jack plug
Measuring function | Measuring range |
Concrete (H2O) | 0 ... 6% |
Cement screed (H2O) | 0 ... 6% |
cement screed | 0 ... 4% |
(Calcium carbide method)* | |
Anhydrite screed (H2O) | 0 ... 3.5% |
anhydrite | 0 ... 1.9% |
(Calcium carbide method)* | |
Caisson scale | 0.3 ... 15.3 m |
Relative scale | 0 ... 100% |
*The calcium carbide method is approximate. | |
Further specification | |
Accuracy | ± 0.5% |
Resolution |
0.1% |
Display | Graphically monochrome, 128 x 64 pixels, |
61 x 33 mm / 2.4 x 1.3 in, backlight | |
Operating conditions | 5 ... 40°C / 41 ... 104°F |
Automatic shutdown | After 5 minutes of inactivity |
Power supply | 2 x 1.5V AA batteries |
Uptime | About 20 hours |
Dimensions | 147 x 89 x 33 mm / 5.8 x 3.5 x 1.3 in |
Weight | Approx. 250 g / < 1 lb (with batteries) |
ex. VAT, ex. delivery costs
Penetration probe with insulated needles (measurement only at the tips), approx. 230 mm long, for PCE-PMI 4, for example, in insulating materials or in joints or holes.
Two needles approx. 230 mm long
Thickness with insulation 4 mm
Variable distance
Cable 920 mm long
of which 460 mm divided
3.5 mm jack plug
