| TR-400 bar PS2W | |
| Measuring range | Resolution |
| 0 ... 400 bar |
0.5 bar |
| 0 ... 5800 PSI | 5 psi |
| 0 ... 408.0 Kg / cm² | 0.5 kg / cm² |
| 0 ... 300000 mm Hg | 500 mm Hg |
| 0 ... 11810 inch Hg | 10 inch Hg |
| 0 ... 4075 meters H20 | 5 meters H20 |
| 0 ... 160600 inches H20 | 200 inches H20 |
| 0 ... 394.5 ATP | 0.5 ATP |
| 0 ... 40000 kPa | 50 kPa |
| Exit | 4 to 20-mA DC |
| 4-mA | = normal pressure |
| 20-mA | = maximum pressure |
| Precision pressure sensor made of ceramic | |
| Linearity output signal | ± 1% FS |
| Zero Offset | ± 2% FS |
| Operating temperatur | -20 ... 80°C / -4 ... 176°F |
| Ambient humidity | 80% RH |
| Size | Ø 30 mm x 85 mm |
| Weight | 160 g / < 1 lb |
