Electromagnetic Radiation Detector PCE-EM 30

Order no.: PCE-EM 30
GTIN (EAN): 4250348707369
US$ 2,425.00
ex. VAT, ex. delivery costs
:
4250348707369
PCE-EM 30
Available in: 1-2 days
Frequency
±2dB
No
Handheld
External
No
No
Your PCE Instruments Benefits
Bilingual Technical Support

Bilingual Technical Support (EN / ES)

Special Promotions

Special Promotions

Public Service, Military and First Responder Discount

Public Service, Military and First Responder Discount

30 Day Return Policy

30 Day Return Policy

2 Year Warranty

2 Year Warranty

Free Standard Shipping (US)

Free Standard Shipping (US)

Accessory

Software for Vibration Meter PCE VT 204
Software for Vibration Meter PCE VT 204
US$ 100.00

Description

PCE-EM 30 Electromagnetic Radiation Detector
Triple-axis electromagnetic field (EMF) detector with data-logging functionality / Comes with two external sensor probes (for low and high frequency ranges)

PCE-EM 30 is a digital portable 3-axis environmental electromagnetic radiation detector or EMF detector used to measure electromagnetic radiation generated by electronic devices and electric installations. This triple-axis EMF meter provides greater precision than single-axis models as well as affords the ability to assess EMFs from more than one source at a time.

Note: USB data cable Incl. software VT-204-SW required for data transfer to PC - please see accessories tab for details.


Highlights

- EMF measuring ranges: 0 to 199.99 V/m, 0 to 99.999 W/m², 0 to 9.9999 mW/cm²
- EMF bandwidth: 100 kHz to 3 GHz
- Measures EMF of 5G cellular Low-band and Mid-band
- Comes with two external sensor probes (for low and high frequency ranges)
- Features a large, easy-to-read LCD screen
- Adjustable alarm value
- Note: USB data cable Incl. software VT-204-SW required for data transfer to PC - please see accessories tab for details

Specification

Bandwidth / Frequency range of the probe EP-03H 100 MHz ... 3 GHz
Range selection for the probe EP-03H900 MHz, 1 GHz, 1.8 GHz,
2.4 GHz, 2.45 GHz, 3 GHz
Bandwidth / Frequency range of the probe EP-04L 100 kHz ... 100 MHz
Range selection for the probe EP-04L100 kHz, 200 kHz, 500 kHz, 1 MHz,
10 MHz, 13.56 MHz, 100 MHz
Accuracy±2 dB
Measuring ranges0 ... 199.99 V/m
0 ... 99.999 W/m²
0 ... 9.9999 mW/cm²
Resolution0.01 V/m
0.001 W/m²
0.0001 mW/cm²
Inital value> 1 V/m
> 0.03 W/m²
> 0.0003 mW/cm²
External sensor probe typesTriple axis
DisplayLCD, 58 x 34 mm / 2.28 x 1.34"
Limit valueAdjustable
AlarmAcoustic signal when limit value is exceeded
Internal memory16,000 data records
Power9 V battery
Operating conditions0 ... 50 ºC / +32 ... +122 ºF, up to 80 % relative humidity (RH)
DimensionsMeter: 200 x 76.2 x 36.8 mm / 7.88 x 3.00 x 1.45"
Probes: 70 x 240 mm / 2.76 x 9.45"
Weight523 g / 1.16 lb (with battery included)

Delivery Scope

1 x Electromagnetic radiation detector PCE-EM 30
2 x external sensor probes
2 x frequency range connectors
1 x 9 V battery
1 x carrying case
1 x user manual

Note: USB data cable Incl. software VT-204-SW required for data transfer to PC - please see accessories tab for details.
