Wind Speed Meter CWG 2

Order no.: CWG 2
GTIN (EAN):
US$ 496.00
ex. VAT, ex. delivery costs
CWG 2
Available in: 1-2 days
Cup vane
Up to 50 m/s
No
Yes (V output)
Your PCE Instruments Benefits
Bilingual Technical Support

Bilingual Technical Support (EN / ES)

Special Promotions

Special Promotions

Public Service, Military and First Responder Discount

Public Service, Military and First Responder Discount

30 Day Return Policy

30 Day Return Policy

2 Year Warranty

2 Year Warranty

Free Standard Shipping (US)

Free Standard Shipping (US)

Accessory

Dual Mounting Arm PCE-CW-T2
Dual Mounting Arm PCE-CW-T2
US$ 152.00

Description

Compact wind speed meter with 0 … 10 V output

Compact wind speed meter CWG 2 for weather monitoring. Basic cup anemometer with 0 … 10 V output.

Highlights

- Basic cup anemometer
- Easy assembly
- 12 m / 39 ft connection cable
- 0 ... 10 V output

Specification

Output0 … 10 V
Measurement range0 … 50 m/s
Accuracy± 0.5 m/s or 3 % or measuring range
Loadmax. 80 m/s short-term
Load 500 Ohm at 15 V operating voltage
Power supply9 … 30 V AC / DC max. 50 mA
Assembly on mast tube
Heatingmax. 24 V DC/AC, max. 20 W
Ambient temperature  -25 … +60 °C /  -13 ... 140 °F (in ice-free conditions)
Cable12 m / 39 ft; LiYY 6 x 0.25 mm²
Protection classIP54
Weightapprox. 500g / 17. 6 oz
ApprovalUL

Delivery Scope

1 x Wind Speed Meter CWG 2
1 x Data Sheet
