CL-IR-Link for changing the settings of the Crowcon Clip SGD gas detector using a PC.manual gas test and calibration
Carbon Dioxide Meter Clip and Clip+ with 24- or 36-month lifetime / triple alarm-signaling / no service or calibration necessary / self-testing function / CO, H2S or O2
This
Carbon Dioxide Meter is a compact and reliable meter, which is built to
guarantee the safety of factory workers. The
Carbon Dioxide Meter has a
lifespan of 2 years and is prepared for every condition that could
possibly emerge in the industry. It’s worth mentioning that while the
Carbon Dioxide Meter Clip+ also has a lifespan of 2 years, it has
an additional standby mode that enables a utilization of the device for
more than 3 years with discontinuity.
The Carbon Dioxide Meter
Clip can measure the parameters for hydrogen sulfide (H2S), carbon
monoxide (CO) and oxygen (O2). The
Gas Leak Detector guarantees
optimal security due to its reliability and the fact that is does not
require any maintenance. At the same time, the
Carbon Dioxide Meter is
uncomplicated so that time-consuming briefings become unnecessary.
Via the
additional software and the IR-link, various alarm-steps can be adjusted,
the measuring data can be shown in real-time, or interpreted and
documented by meanings of the integrated IR- interface. The
Carbon Dioxide Meter also notifies the user if a gas - detection should become
necessary (Bump-test). As previously mentioned, the
Carbon Dioxide Meter is prepared for any conditions that could emerge in the industry.
Measurements can be executed at a temperature range of -40 to +50°C / -40 to 144°F or
relative humidity of 5 to 95%. The
Carbon Dioxide Meter has IP 66 and 67
standard protections and, with measures of 81 mm x 50 mm x 28 mm / 3.2 x 2 x 1.1 in, they are
very compact.
Technical specification of the Carbon Monoxide Meter Crowcon Clip/Clip+ | |||
Measuring ranges and alarm level of Carbon Monoxide Meter Crowcon Clip | |||
Gas | Measuring range sensor | Alarm1 | Alarm 2 |
H2S | 0 ... 100 ppm | 5ppm | 10 ppm |
CO | 0 ... 300 ppm | 30ppm | 100 ppm |
O2 | 0 ... 30% Vol. | 19% Vol. | 23.5% Vol. |
Common technical data for the Gas Alerter Crowcon Clip/Clip+ | |||
Operation time | 24
months nonstop operation Clip 36 months with standby mode Clip+ if max. 4 minutes alarm duration daily | ||
Storage option | Max. 1 year before first activation | ||
Display | LCD, Remaining life, gas level and further information | ||
Alarm
display optic acoustic haptic |
LED on top, bottom and sidewise 95 dB Vibration | ||
Self-test | Every 2 hrs. after turn-on, constant battery monitoring | ||
Power Supply | Internal battery | ||
Environmental
conditions H2S CO O2 | -40 ... +50°C / -40 ... 122°F / 5 ... 95 % r.h. non-condensing -40 ... +50°C / -40 ... 122°F / 5 ... 95 % r.h. non-condensing -35 ... +50°C / -31 ... 122°F / 5 ... 95 % r.h. non-condensing | ||
Dimensions | 81 x 50 x 28 mm / 3.9 x 2 x 1.1 in | ||
Weight | 76 g / < lb | ||
Protection type | IP 66/ IP 67 | ||
Compliance | EMC- guideline 89/336/EWG | ||
Certification | UL-913
& CSA-C22.2 Nr.157 Class 1 Div. 1 and 2, Group A, B, C, D ATEX II 1G Ex ia IIC T4 Ga IECEx Ex ia IIC T4 |
