Chimney Camera

£ 1,246.00

Price excl. VAT &. delivery
2 year Warranty

PCE-VE 390N is the ideal downhole inspection camera for the evaluation of homes and buildings (walls, supports, eaves, gutters, attics, crawl spaces), plumbing (pipes, drains, sewers, wells) and heating, ventilation, air conditioning and refrigeration (HVACR) systems (ducts, furnaces, chimneys, boiler and condenser tubes).

Camera head diameter: 28 mm / 1.11 in
Camera cable length: 10 m / 32 ft
Interface: Mini-USB 1.1 and AV out
Memory: 8 GB SD memory card (incl.)
Especially suitable for chimneys, downpipes, ventilation ducts etc.

Chimney Camera PCE-PIC 20

£ 1,771.00

Price excl. VAT &. delivery
2 year Warranty

The chimney camera is an ideal tool for any service technician who needs to visually inspect pipes and ducts. The chimney camera has a 23 mm / 0.9 in camera head, which is attached to a glass fiber push cable.

Cable diameter / head diameter: 23 mm/ 0.9 in
20 m / 66 ft push cable
Electronic meter counting
Battery and mains operation
Waterproof up to 20 m / 66 ft

Chimney Camera PCE-VE 380N

£ 1,780.00

Price excl. VAT &. delivery
2 year Warranty

The chimney camera or inspection camera with a handheld monitor that allows you to gain valuable visual insight into the inner workings of machines and other small spaces such as ventilation ducts, drainpipes and downpipes, sewer pipes, chimneys and more. This semi-flexible / semi-rigid waterproof chimney camera is ideal for a variety of industrial and trade applications. Images and videos can be stored directly on the device or on the included SD memory card.

Diameter camera head: 28 mm / 1.11 in
Camera head waterproof
Camera cable length: 30 m / 98 ft
SD memory card
Bright LED lighting

Chimney Camera PCE-PIC 40

£ 2,124.00

Price excl. VAT &. delivery
2 year Warranty

Cable diameter / head diameter: 23 mm / 0.9 in
40 m / 131 ft push cable
Electronic meter count
Battery and mains operation
Waterproof up to 20 m / 66 ft

Chimney Camera PCE-VE 1030N

£ 2,661.00

Price excl. VAT &. delivery
2 year Warranty

The chimney camera PCE-VE 1030N is a versatile videoscope or video borescope inspection camera with a large 7" high-resolution display. This chimney camera captures and stores both picture and video. Video recordings are accompanied by audio for a more immersive inspection experience.

Cable length: 30 m / 98 ft
Camera head diameter: 28 mm / 1.1 in
SD card memory included
Waterproof cable and camera

Chimney Camera PCE-VE 380N-LOC

£ 2,868.00

Price excl. VAT &. delivery
2 year Warranty

The chimney camera provides you with new, optical insights into the inner workings of machines and systems as well as in cavities, ventilation ducts, down pipes, chimneys, sewage pipes… The chimney camera is the ideal tool for maintenance and repair in any industrial area, craft or workshop.

Camera head diameter : 28 mm / 1.11 in
Waterproof camera head
Camera cable length: 30 m / 98ft
SD memory card
Bright LED lighting
incl. Locator (to locate the damaged area)

Chimney Camera PCE-PIC 60

£ 11,208.00

Price excl. VAT &. delivery
2 year Warranty

The chimney camera PCE-PIC 60 is used to inspect channels and pipes. The chimney camera has a fiber optic push cable of 60 m. At the end of the chimney camera, a motorized camera head is mounted. This camera head is able to be moved 360° horizontally and 180° vertically.

Camera head diameter : 60 mm / 2.4 in
Cable length: 60 m / 196.9 ft
Pipe diameter to & from: 80 … 1200 mm / 3.1 … 47.2 in
Field of view: 20 … 100 cm
SD card up to 256 GB
ø9.5 mm fiber optic cable
Motorized camera
With cable trolley

Chimney Camera PCE-PIC 120

£ 12,231.00

Price excl. VAT &. delivery
2 year Warranty

The chimney camera is used to inspect waste water channels and pipes. This chimney camera has a fiber optic push cable of 120 m / 393.7 ft. At the end of the chimney camera, a motorized camera head is mounted. This camera head is able to be moved 360° horizontally and 180° vertically.

Camera head diameter: 60 mm / 2.4 in
Cable length: 120 m / 393.7 ft
Pipe diameter from & to: 80 … 1200 mm / 3.1 … 47.2 in
Field of view: 20 … 100 cm
SD card up to 256 GB
ø9.5 mm fiber optic cable
Motorized camera
With cable trolley

More Information about the Chimney Cameras

A chimney camera is a special design of an endoscope, and presents an optical inspection tool for cavities or hard-to-reach areas. The chimney camera is used especially for the inspection of the chimneys in order to detect the damaged areas, leaks etc. The problems with chimneys are often caused by the clogging, in the old pipes, cracks may occur, which leads to the damage as well.

With the help of the chimney camera, there is no need to release the affected chimney first and then disassemble it before it can be examined. The chimney camera has a camera head attached to a push cable. The camera head is very bright and therefore it is possible to transfer a very good picture from the observed areas. Likewise, chimney cameras are equipped with a comparatively large camera sensor. These CMOS sensors are very sensitive to light and thus make a good image in the low-light conditions. Due to the larger camera sensor, chimney cameras can often achieve a higher resolution than normal inspection endoscopes.

Of course, chimney cameras are completely waterproof due to the intended application purpose and some models are also highly IP-protected. The cameras are protected by the protective covers against scratches and other damages. A nano-coating of the protective cover ensures that dirt and moisture immediately roll off, so that the picture taken by the chimney camera is not spoilt.

For centering in the drains, a centering brush can be installed on the camera head of the chimney camera. Furthermore, this brush ensures that if there are contaminants in the pipe, they do not gather in front of the camera and thus complicate a chimney inspection.

The chimney cameras have a fiber optic push cable / push rod that can be moved quite well over longer distances. The quasi-rigid design makes the working process with the chimney camera trouble-free.

The recorded images and videos can be stored by the chimney camera in the central unit and transferred to a PC or laptop for further analysis or documentation. Afterwards, a very accurate, punctiform repair of the chimney can be carried out.

When purchasing the chimney camera, you should be sure about the crucial points, because the choice of the appropriate model is very important for obtaining good results. It is necessary to consider when, how often and for which purpose the chimney camera is needed. If the application areas are clear, then it can be decided which size, performance and settings the new chimney camera must have.

The chimney cameras are available in different versions. There are chimney cameras, which have only a very rigid field of view. Here, it is only possible to inspect the chimneys at a 0 ° angle forward. But there are also chimney cameras, on which the front camera can be moved 360 ° with the help of the motors. With this chimney camera, an all-round inspection of the chimney is possible.

Furthermore, the offered chimney cameras have a length measuring device. This meter counting function helps the inspector find the exact point of any damage in the pipes and chimneys. In addition, for some chimney cameras, a locator is optionally available. This locator detects the position of the camera head via a radio signal and, thus, determines the exact position. This optionally available locator is even capable of measuring the depth of the camera head.

If you have a special application, we are happy to give you an advice or consultation in order to find the right chimney camera for you.
