Thermal Imaging Camera

PCE Instruments (PCE) offers a number of thermal imaging camera products for use in home, electrical and machine inspections, security applications and more. Each PCE-branded thermal imaging camera features a user-friendly interface, so you don't need to be an expert to capture and analyze thermal images. The various thermal imaging camera models offered by PCE are smaller, more durable, easier to use and more economical than traditional thermal imaging devices. Each thermal or infrared imaging camera has a streamlined design that allows for the utmost convenience in portability.

Taking infrared measurements using a thermal imaging camera allows for the detailed analysis of a particular scenario. Thus, the possible uses for a thermal imaging camera are extensive. For example, a thermal imaging camera is a useful tool for inspectors, security personnel, builders, architects, electricians, HVAC technicians, engineers, scientists and researchers. Thermal imaging devices help law enforcement professionals and investigators to determine the infrared characteristics of various forensic materials. Thermal Imaging Cameras also are used by mold remediation specialists to detect temperature variations behind walls, as cold spots can indicate potential moisture. Once a cold spot is located, a moisture meter is used to test the area to confirm the presence of water.

If you have any questions, please contact us at or +44 ( 0 ) 161 464902 0.

Thermal Imaging Camera PCE-TC 28

£ 548.00

Price excl. VAT &. delivery

The Thermal Imaging Camera PCE-TC 28 was designed for taking non-contact temperature measurements. To get accurate readings, the emissivity of the thermography camera can be adjusted, depending on the operation purpose. Besides taking infrared images, the thermography camera can also take normal pictures, as well as a mixture of both, due to the built-in digital camera.

Measurement range: -20 … +600°C / -4 … 1112°F
Accuracy: ±2%, ±2°C / 3.6°F
Frequency image recording: 9 Hz
Camera: 32 x 31 Pixel

Thermal Imaging Camera PCE-TC 28-ICA incl. ISO Calibration Certificate

£ 759.00

Price excl. VAT &. delivery

Measurement range: -20 … +600°C / -4 … 1112°F
Accuracy: ±2%, ±2°C / 3.6°F
Frequency image recording: 9 Hz
Camera: 32 x 31 Pixel- incl. ISO Calibration Certificate

Thermal Imaging Camera PCE-TC 30N

£ 674.00

Price excl. VAT &. delivery

The PCE-TC 30N thermal imaging camera for preventive maintenance is the ideal tool for maintenance and servicing. This thermal imaging camera is a must-have for electricians, fitters or general maintenance personnel for troubleshooting and fault prevention of electrical equipment, electromechanical devices, production process machinery, heating, ventilation and air conditioning systems, especially when working in harsh environments.

IR resolution: 160 x 120 pixels
Measuring range: -20 … 450°C / -4 … 842°F
Thermal sensitivity: 70 mK
Memory: 3 GB memory for more than 20,000 pictures
5 different color palettes
Hot and cold spot location
Picture in Picture function

Thermal Imaging Camera PCE-TC 30N-ICA incl. ISO Calibration Certificate

£ 890.00

Price excl. VAT &. delivery

IR resolution: 160 x 120 pixels
Measuring range: -20 … 450°C / -4 … 842°F
Thermal sensitivity: 70 mK
Memory: 3 GB memory for more than 20,000 pictures
5 different color palettes
Hot and cold spot location
Picture in Picture function
incl. ISO Calibration Certificate

Thermal Imaging Camera PCE-TC 33N

£ 691.00

Price excl. VAT &. delivery

In preventative maintenance, the high-resolution PCE-TC 33N thermal imaging camera is ideal for maintaining or repairing machinery or other equipment. The heart of the high-resolution thermal imaging camera PCE-TC 33N is an uncooled microbolometer (uncooled focal plane array) with a resolution of 220 x 160 pixels.

IR resolution: 220 x 160 pixels
Measuring range: -20 … 300°C / -4 … 572°F
Thermal sensitivity: 70 mK
Memory: 3 GB memory for more than 20,000 pictures
5 different color palettes
Hot and cold spot location
Picture in Picture function

Thermal Imaging Camera PCE-TC 33N-ICA incl. ISO Calibration Certificate

£ 926.00

Price excl. VAT &. delivery

IR resolution: 220 x 160 pixels
Measuring range: -20 … 300°C / -4 … 572°F
Thermal sensitivity: 70 mK
Memory: 3 GB memory for more than 20,000 pictures
5 different color palettes
Hot and cold spot location
Picture in Picture function
incl. ISO Calibration Certificate

Thermal Imaging Camera PCE-TC 32N

£ 863.00

Price excl. VAT &. delivery

The thermal imaging camera has a measuring range of -20 … +550 °C. This means that the thermal imaging camera already covers a wide temperature range of measuring tasks. With an image frequency of 25 Hz, problems can be quickly localised with the thermal imaging camera.

Measuring range: -20 … +550 °C
Picture-in-picture function
Frame rate: 25 Hz
Internal/external memory
Wi-Fi 802.11
Display resolution: 240 x 320 pixels
Battery

Thermal Imaging Camera PCE-TC 32N-ICA incl. ISO Calibration Certificate

£ 1,092.00

Price excl. VAT &. delivery

Measuring range: -20 … +550 °C
Picture-in-picture function
Frame rate: 25 Hz
Internal/external memory
Wi-Fi 802.11
Display resolution: 240 x 320 pixels
Battery
- incl. ISO Calibration Certificate

Thermal Imaging Camera PCE-TC 26

£ 432.00

Price excl. VAT &. delivery

The Thermal Imaging Camera is a versatile instrument for industrial maintenance, building inspection and fault diagnosis in electrical systems. With a temperature range of -10 °C ... +400 °C, the Thermal Imaging Camera can be set to focus on specific inspection areas and can detect temperature changes of 0.05 ℃ with an error of only ±2 %.

measurement range: -10 ... +400 °C
resolution: 0.1 °C
accuracy: ±2 °C
frame rate: 25 Hz
Display resolution: 120 x 90 pixels
thermal sensitivity: 0.06 °C
field of view: 38 ° (H) x 50 ° (V)

Thermal Imaging Camera PCE-TC 20

£ 512.00

Price excl. VAT &. delivery

The Thermal Imaging Camera is a device that can be used in many areas such as building inspection, vehicle maintenance, underfloor heating detection and electrical inspection. The Thermal Imaging Camera covers a measurement range of -20 °C ... +400 °C and enables precise temperature measurements with a resolution of 0.1 °C.

temperature: -20 °C ... +400 °C
resolution: 0.1 °C
accuracy >0 °C: ±2 °C or ±2 %
accuracy ≤0 °C: ±5 °C or ±5 %
storage medium: internal, micro SD card
file format: .bmp
camera: 120 x 90 pixels

Thermal Imaging Camera PCE-TC 38

£ 1,742.00

Price excl. VAT &. delivery

Our Thermal Imaging Camera offers reliable temperature measurement within a range from -20 °C to 550 °C (-4 °F to 1022 °F). The infrared images are displayed with a resolution of 384 x 288 pixels on the 3.5 inch colour display. The Thermal Imaging Camera saves more than 40,000 images in the internal 6 GB memory in JPG format.

measurement range: -20 ... 550 °C
infrared image resolution: 384 x 288 pixels
frame rate: 25 Hz
wavelength range: 8 ... 14 µm
emissivity: 0.01 ... 1
