124,90 €
- High accuracy
- High robustness
- Characteristic curves AS / NZS 1080.1
- Adjustable characteristic values of wood
- Adjustable characteristic values of any material
- Adjustable characteristic paper values
- Temperature correction (manually)
- Detector of resistance humidity
- Adjustable auto shut-off
- Diverse humidity probes can be adapted to the detector
- Additional calibration block
| Technical specifications | ||
| Measurement ranges | 5 ... 99 % H2O for wood
0 ... 99 % H2O for building materials |
|
| Resolution | 0.1 % | |
| Accuracy | 0.3 % | |
| Measurement depth | depends on the selected sensor | |
| Measuring principle | measurement of resistance humidity | |
| Temperature range | 0 ... 50 °C / 32 ... 122 °F | |
| Power | 1 x 9 V battery
selectable Auto Power Off to protect the battery |
|
| Dimensions | 160 x 80 x 30 mm / 6.2 x 3.1 x 1.1 in | |
| Weight | 260 g / 9.1 oz with the battery included | |
Standard driving-in sensor
For wood and building materials
(with short pins without isolation / isolated long pins)
Universal probe holder
It is
used to hook up all the special sensors: head sensors for surfaces (to measure
without causing damages in the material), surface sensors with short and
extra-long pins.
Surface humidity sensor with 4 x 1,5 mm pins
It is hooked up with both pins to the universal probe holder. Humidity is measured with 4 x 1.5 mm length pins on a rounded metal surface divided into two parts. It specially measures moisture content of cork, rubber, soft building materials and roof insulators.
Equipment for humidity in concrete
To accurately measure humidity in diverse concrete depth.
Pile driver electrode
Higher penetration strength for both hard wood and hard building materials (it can be hammered)
Head sensor for surfaces
It is hooked up with both plugs to the universal probe holder / humidity is measured in the black measuring surface / This contact sensor works without causing any damages in the material / It is specially indicated to measure humidity on printed wall-papers, plastics, valuable woods and other building materials where it is important to measure without causing any damage.
Humidity sensor with 4 x 17 mm pins
It is hooked up with both plugs to the
universal probe holder
Humidity sensor with extra-long pins
It is hooked up with both plugs to the universal probe holder / Humidity is measured by the two ends of the pins / It is especially suited for great diameter woods, beams, timber planks as well as for diverse insulation materials and fiber or for light building foam materials as foams.
