194,90 €
Technical Specifications | |
Measurement ranges | 0 ... 200 mΩ / 100 μΩ 0 ... 2000 mΩ / 1 mΩ 0 ... 20 Ω / 10 mΩ 0 ... 200 Ω / 100 mΩ 0 ... 2000 Ω / 1 Ω |
Accuracy | ± 0.5 % of the measurement value, ± 2 digits along the entire range of the operating temperature: -15 ... +55 °C (in measurements with the attached testing cables) |
Test current | 1 mA (range of 2000 Ω) 10 mA (range of 200/20 Ω) 100 mA (range of 2000 m Ω/ 200 mΩ) |
Test current accuracy | ± 0.1 % |
Max. output voltage (C1-C2) | 20 V |
Power | 8 x 1.5 V (AA) batteries |
Dimensions | 250 x 190 x 110 mm |
Weight | 1.5 kg |
Standard | IEC-1010-1; CAT IV 20 V |
