Specification
| TR-PS2W-10BAR |
|
| Measuring range |
Resolution |
| 0 ... 10 bar |
0.01 bar |
| 0 ... 145 PSI |
0.2 PSI |
| 0 ... 10.19 Kg / cm² |
0.01 kg / cm² |
| 0 ... 7500 mm Hg |
10 mm Hg |
| 0 ... 295.2 inch Hg |
0.2 inch Hg |
| 0 ... 101.9 meters H20 |
0.1 meter H20 |
| 0 ... 4010 inches H20 |
5 inch H20 |
| 0 ... 9.87 ATP |
0.01 ATP |
| 0 ... 1000 kPa |
1 kPa |
| |
|
| Exit |
4 to 20-mA DC |
| 4-mA |
= normal pressure |
| 20-mA |
= maximum pressure |
| Precision pressure sensor made of ceramic |
| Linearity output signal |
± 1% FS |
| Zero Offset |
± 2% FS |
| Operating temperatur |
-20 ... 80°C / -4 ... 176°F |
| Ambient humidity |
80% RH |
| Size |
Ø 30 mm x 85 mm |
| Weight |
160 g / < 1 lb |
| |
|
Delivery Scope
1 x Pressure sensor TR-PS2W-10BAR
