151,90 €
General parameter | ||
Frequency range | 0…120,000 FPM (flashes per minute) | |
Voltage supply | 24 VDC (+/- 10%) / 40 W DIN 41524 5pin Standardstecker Universelles Netzteil verfügbar | |
External triggerinput | 3...30 V / max. 5 mA (potential freeOptokoppler) DIN 41524 5pin Standardstecker Uout = Uin, max. 200 mA Triggerinput switchable | |
Triggeroutput | for parallel circuit | |
Flash Parameter | ||
Flash period | 1–1000 μSec. (adjustable) | |
Luminous intensity | standard, 30 – 100% | |
Light intensity single flash | ca. 20 Mega-Lux / 30 cm / 12" | |
Light intensity max. | 9.000 Lux @ 30 cm / 12˝ | |
Illumination area | 300 x >500 mm / 12 x >20˝ | |
Light colour | ca. 5,000…8,300 K | |
Case | ||
Material | Aluminium | |
Diameter | 440 x 130 x 112 mm / 17.3 x 5,1 x 4.4˝. | |
Weight | 2.100 g | |
Ambient conditions | ||
Ambient temperature | 0...40 °C (32...104 °F) | |
Storage temperature | -25...70 °C (-13...158 °F) | |
Humidity | Max. 95 %, non-condensing |
