| Rated load / force F.S. | 5 / 10 / 20 / 30 / 50 / 100 kg 50 / 100 / 200 / 300 / 500 / 1000 N ! Rated load / force selectable ! |
| Limit load / force | 120 % |
| Breaking load / force | 150 % |
| Rated output | 1.0 – 1.5 mV/V |
| Operating range of supply voltage | 2.5 V – 5 V |
| Maximum supply voltage | 5 V |
| Deviations of the zero signal | ± 2 % F.S. |
| Linearity deviation | 1.0 F.S. |
| Reverse voltage (hysteresis) | 1.0 F.S. |
| Repeatability | 1.0 F.S. |
| Stress creep (30 min) | 0.1 F.S. |
| Input resistance | 350 ± 10 Ω |
| Output resistance | 350 ± 3 Ω |
| Insulation resistance | ≥5000 MΩ / 100 VDC |
| Nominal range of ambient temperature | -10 … 60 °C / 14 ... 140 °F |
| Service temperature range | -20 … 80 °C / -4 ... 176 °F |
| Temperature coefficient of characteristic value | 0.1 % F.S. / 10 °C / 50 °F |
| Temperature coefficient of zero point | 0.1 % F.S. / 10 °C / 50 °F |
| Sensor cable | Ø 2 x 3 m / 6 ft 6" x 9ft 10" (ends open) |
| Cable assignment | EXC+ = red EXC- = black SIG+ = green SIG- = white GND = yellow |
| Material / measuring body | stainless steel |
| Protection | IP65 |
| ! N.B. Rated load / force selectable ! | |
