3.256,90 €
Price excl. VAT &. delivery
2 year Warranty
2 year Warranty
The videoscope with side view camera gives you new, visual insights into the interior of motors and systems. The videoscope with side view camera is the ideal tool for maintenance and repair in workshops or industrial companies. Optical analysis with a videoscope has never been so easy.
The videoscope gives you new, visual insights into the interior of motors and systems. The industrial videoscope is the ideal tool for maintenance and repair in workshops or industrial companies. Optical analysis with an videoscope has never been so easy.
With this videoscope, weld seams, wear and tear and damage can be assessed quickly and easily in order to make quick diagnoses. The sheathing of the endoscope cable from the videoscope consists of braided tungsten.
With this videoscope, weld seams, wear and tear and damage can be assessed quickly and easily in order to make quick diagnoses. The sheathing of the endoscope cable from the videoscope consists of braided tungsten.
With this videoscope, weld seams, wear and tear and damage can be assessed quickly and easily in order to make quick diagnoses. The sheathing of the endoscope cable from the videoscope consists of braided tungsten.
The PCE-MM 800 microscope is designed to display simple magnifications on a computer screen. For this purpose, the PCE-MM 800 microscope is connected to a screen. This allows a large presentation visible by several people.
Thanks to the integrated 7.62 cm / 3" TFT color display and Li-Ion batteries, the Videoscope can be PC-independent and therefore used completely mobile. Equipped with 8 white LEDs increases the Videoscope up to a 500-fold size and thus captures even the smallest details in image or video.
PCE-VE 180 is a rechargeable handheld pistol-grip videoscope or video borescope inspection camera with video recording and image capture functionality. Equipped with built-in LED lighting on the waterproof camera tip, the PCE-VE 180 borescope features a detachable remote control with integrated 3.5" LCD for easy viewing and navigation. The remote control communicates using radio transmission at 2.4 GHz.
PCE-VE 200 is an industrial inspection camera, endoscope or borescope for the non-destructive evaluation (NDE) of engines, machines and more. This industrial borescope provides excellent image quality at an affordable price. An ideal tool for diagnosing issues in hard-to-reach places, the waterproof camera head features 6 LED lights with adjustable intensity for optimal illumination. In addition, digital image magnification or zoom of up to 4 times is available.
The PCE-VE 200SV1 videoscope is a nondestructive inspection camera. Thus, the PCE-VE 200SV1 videoscope is the ideal instrument for diagnosing hard-to-reach areas. Thus, the areas of mechanical engineering, sanitary and heating construction, and the entire construction industry are among the main applications of the videoscope camera PCE-VE 200SV1.
The videoscope is an inspection camera for non-destructive measurements. Thus the videoscope is the ideal instrument for diagnosis in hard-to-reach places. Mechanical engineering, sanitary and heating engineering and the entire building and construction industry are among the main areas of application for the videoscope.
PCE-VE 200-S is an industrial inspection camera, endoscope or borescope for the non-destructive evaluation (NDE) of engines, machines and more. This industrial borescope provides excellent image quality at an affordable price. An ideal camera tool for diagnosing issues in hard-to-reach places, the waterproof camera head features 6 LED lights with adjustable intensity for optimal illumination. In addition, digital image magnification or zoom of up to 4 times is available.
PCE-VE 200-S3 is an industrial inspection camera, endoscope or borescope for the non-destructive evaluation (NDE) of engines, machines and more. This industrial borescope provides excellent image quality at an affordable price. An ideal tool for diagnosing issues in hard-to-reach places, the waterproof camera head features 6 LED lights with adjustable intensity for optimal illumination. In addition, digital image magnification or zoom of up to 4 times is available.
PCE-VE 200 is a videoscope or inspection camera for nondestructive evaluation (NDE) and machine diagnostics. The PCE-VE 200 videoscope provides excellent image quality at an affordable price. An ideal camera tool for diagnosing hard-to-reach places, the scope can be rotated 180° and offers 6 LED lights with adjustable intensity for optimal illumination. In addition, digital image magnification or zoom of up to 4 times is available.
Videoscope
PCE Instruments' engineers and technicians will be happy to assist you in finding the right videoscope inspection camera to suit your application and desired specifications. Nevertheless, we would like to give you some useful information that will help you make the right decision when selecting your videoscope.
Important factors to bear in mind when looking for a videoscope
- Type of videoscope camera cable
- Needed length / diameter of videoscope camera cable
- Memory for images and videos
- Technical support
Type of videoscope camera cable
A rigid engine videoscope cable usually has a rather small diameter to allow the inspection of very confined spaces. Most industrial rigid videoscopes are analogue, which means that users cannot record and process images and videos without using a special adaptor.
If you still want to process your images and videos, you can purchase an adaptor for your videoscope separately.
Depending on your application, you can choose a videoscope with a rigid or flexible videoscope cable. Flexible cables are available with 2- or 4-way articulating systems. An articulation system enables you to move the videoscope camera head in different directions and angles up to 360 °. Through flexible videoscope cables, images are transferred to the handheld device via a glass fibre bundle or via the camera which is located in the cable. The latter particularly applies to the modern digital videoscopes offered by PCE Instruments. PCE’s flexible videoscope camera cables are available in many different lengths and diameters, which makes our videoscopes suitable for nearly any application.
Needed length / diameter of videoscope camera cable
As mentioned before, PCE’s flexible videoscope camera cables are available in many different lengths and diameters to suit your specific application. Generally, the needed videoscope cable diameter is determined by measuring the openings of the pipes, engines, machine components, etc. to be inspected. The cable length obviously should not be too short. You may want to use your industrial videoscope for several applications which can sometimes mean that you need several cables with different lengths and diameters.
In this case, we recommend you to buy an engine videoscope that accommodates multiple cable diameters and lengths. These have the huge benefit of relatively low follow-up costs as you will not need to buy new cables with different lengths and diameters later on.
Memory for images and videos
Before purchasing a videoscope, make sure to take into consideration if you need the function of recording and storing images and videos of your inspection. Lots of modern digital videoscopes come with a removable SD card that makes it easy to download your images and videos and view them on your computer. Some of PCE Instruments’ videoscope cameras come or are available with an analytical software to evaluate your results. For example, these softwares are very helpful when you want to document the progress of cracks or fractures in your objects of inspection.
Technical support
PCE Instruments offers technical support and qualified customer service. PCE Instruments' engineers and technicians will ask you the right questions to find the best engine videoscope or videoscope camera. For advice, call +44 (0) 2380 987 035 for PCE Instruments UK or +1 (561) 320-9162 for PCE Americas Inc.
