Description

Balance for Pharmacies PCE-LS 3000 (Legal For Trade / Class II)
Weighing ranges of 0 ... 500 and 0 ... 3000 g / resolutions 0.001 g, 0.01 g) /
LCD graphic display / internal, external calibration / RS-232-interface and optional software

The verifiable Industrial Scale comes in two models (LS-500 and LS-3000). The back-lit, high-contrast graphic display of this Industrial Scale leads the user safely through the process; lengthy instructions and operator errors are a thing of the past. All LS models can be calibrated / adjusted automatically at the touch of a key, at a pre-set time, or triggered by temperature changes. Without the need to handle expensive external weights, these functions support integration in quality management systems. The large weighing platform of the scale is a real added plus for weighing larger objects. The integrated RS-232-interface enables you (by using the optional software-kit) to automatically send the weighing data into a sequence table. LS Series of Jewellery Scale have been designed to meet the applications of laboratories, schools, universities, industry and commercial users, without the high cost implications usually found with this type of scale.

Precision Scale PCE-LS series: Verifiable professional grade.

In the upper image a PCE-LS 500 series Industrial Scale with a round weighing pan with 120 mm diameter is shown. The lower image shows a PCE-LS 300 series Industrial Scale with a square weighing pan (165 x165 mm). Both weighing pans have been made with stainless steel and can be used for all kind of laboratory issues, production and research.

Highlights

- Internal calibration (with internal weight)

- External calibration (if the scale is not verified)

- Parts counting function

- Full tare range

- Date and time / User Identification

- Graphic LCD with backlit / Capacity tracker

- Multilingual display (English, German, French, ...)

- RS-232 bi-directional interface

- Verifiable ("Legal for trade") Class II

- SO Calibration certificate (Option)

- Software-Kit (Option)

- Density Determination Kit, Printer (Option)

Characteristics of the scales.

See / Print

Instruction manual Data sheet

Precision Scale PCE-LS series: LS Series (graphic display with capacity tracker).

Apart from the digital reading of the weighing data and the large graphic LCD display, this Industrial Scale comes with a range strip (0 ...100 %) to check the used range directly. Besides, you will adjust both the intensity and the back light through the keypad. The upper image shows the display of the Industrial Scale with the back light off.

A verified Industrial Scale is recommended to be used to prepare medicines in pharmacies as well as for the analysis in medical and pharmaceutical laboratories. So, it is important to bear in mind the scale usage scope. If you wish, a calibration can be carried out by PCE-Group.
An official verification is required when the analytical scale is used for:
a) Trade relations when the price of the product is determined by its weight.
b) Preparation of medicines in pharmacies as well as for the analysis in medical and pharmaceutical laboratories.
c) Determination of rates, tariffs and official fines as well as for official and objective surveys in judgements.
d) Manufacturing of packages.
Every analytical scale is checked by the official authorized centre to provide it with a verification certificate. Besides, precision is determined within the permitted tolerance framework. EU Verification is valid for all the countries members of the EU (European Union).

Specification

Technical Specifications

Scale model	PCE-LS 500	PCE-LS 3000
Maximum capacity [max]	500 g	3000 g
Readability [d]	0,001 g	0,01 g
Verification value [e]	0,01 g	0,1 g
Repeatability	0,0015 g	0,015 g
Linearity	± 0,002 g	± 0,03 g
Stabilisation time	< 5 s
Minimum parts weight at pcs counting	0,006 g / pcs	0,06 g / pcs
Tare range	Full
Vibration dampening	Function which allows vibration dampening settings
Interface	RS-232 bi-directional interface
Software-Kit	As an option
Display	Graphic display with backlit (multilingual) and capacity tracker
Calibration	- Automatic calibration with internal calibration weight (each 2 h or at temperature change) - External calibration with optional weights (only if the scale is not verified)
Pan size	Diameter 120 mm	165 x 165 mm
Operating Temperature	+18 ... +33 °C
Power supply	230V / 50 Hz (via 12 V Net adaptor)
Housing	die cast aluminium
Protection	IP 54
Overall dimensions	210 x 320 x 90 mm
Net weight	5 kg
Approvals	Legal for Trade Class II scale / CE

Calibration of the Industrial Scale

Calibration: To meet with the UE 90 / 384 / EWG standard, all counting scales must be officially calibrated to be used for:
a) Trade relations when the price of the product is determined by its weight.
b) Preparation of medicines in pharmacies as well as for the analysis in medical and pharmaceutical laboratories.
c) Determination of rates, tariffs and official fines as well as for official and objective surveys in judgments.
d) Manufacturing of packages.

Every scale can be checked by the official authorized centre to provide it with a Calibration certificate. Besides, precision is determined within the permitted tolerance framework. EU calibration is valid for all the countries members of the EU (European Union).

Scale calibration with CAL adjusting program: The adjusting program is marked with an official mark once calibration has been carried out. Calibration will be valid for the given location. So, it is necessary to provide with the location of the scales by means of the postal code to prepare calibration. Calibration can be performed in the company or in the location of the scale depending on the scale.

Calibration of a scale with adjustment of automatic change: There are not any limitations depending on the location of the scale due to the fact that the automatic adjustment can be used after a calibration has been done, i.e. it is not sealed. In this case, calibration will not depend on location.

Calibration value: measurement of calibration tolerance which is nearly ever between 1 and 10 d.

Delivery Scope

Delivery content
1 x Industrial Scale PCE-LS 3000, 1 x Net adaptor, User manual (in needed language: english, russian, italian, french, spanish ...)
