Calibration interval: to perform correct
measurements, devices must be calibrated at regular intervals. This
period of time is called calibration interval. It is difficult to determine this period with accuracy but you should consider the following factors:
• Measuring magnitude and permitted tolerance limit
• Performance of the measuring instruments
• Frequency of use
• Operating conditions
• Previous calibrations stability
• Measuring accuracy required
• Determining factors of the quality control systems used by companies
This means that the user is in charge of checking and controling the interval between calibrations. We recommend that this interval between calibrations should be between 1 and 3 years.
Certificate of conformity: A verification certificate which is issued by the Verification Centre.
Certification according to DIN EN ISO 9001: the certification shows that a company meets with all the required quality management system according to
DIN EN ISO 9001 standards. After speaking with the appropriate
authorities, a certificate can be obtained according to the quality
management system standard DIN EN ISO 9001.
Certificate of inspection: Manufacturer’s certification which confirms that the instruments meet all the technical specifications (technical sheet).
Control and measuring instruments: they cover all the meters, visual display units and references that are used in the development and manufacture of a product for purposes of measuring qualitative relevance. (Manufacturers of meters).
Go to the top
Declaration of conformity: the declaration of conformity documents that a product corresponds with EU directives.
Digital interfaces: For the connection to a PC or to a meter (SPS). It allows to transfer measurement values in digital form for further analysis or to set meters through the PC. Some examples are RS485, RS232, Profibus DP.
Display: It displays physical, chemical and biological quantities.
Display range: Maximum and minimum values which can be displayed.
Go to the top
Factory certification: Manufacturer’s certification which confirms that the instrument meet all the technical specifications (technical sheet).
Factory calibration certificate: Factory calibration certificates are issued with standards which are subject to a regular control or the calibration instruments. Meters are adjusted through control and calibration devices.
Go
to the top
Indication of an overload: shown on the display of meters (OL) when a minimum or maximum load is exceeded.
This overload can damage meters.
Interface: Connection port to connect meters to a computer for measurement values to be transferred.
ISO 9000: Quality control system (DIN) for quality controls in the company.
Ingress protection (ip): the higher the number,
the better protection against dust and water that the meter's
enclosure has. IP 54 is standard.
Go to the top
LCD display (liquid crystal display): term used to identify a type of display which incorporates liquid crystal and is not illuminated on its own.
LED display (light emitting diode): it uses the light emitted from light diodes to display values or indicators.
Logical zero: Both current and voltage signals in control systems in which the lowest value is not equal to zero but they have a logical zero. A well known example is the 4-20 mA signal. When transferring this signal, it should not occur below 4 mA. A signal with logical zero has two advantages: On one hand, it can detect and show an error, and on the other hand the sensor can use the signal as a power source.
Loop system: The control of an input signal, which by means of a response can close one circuit, is called loop system.
Go
to the top
Measurement deviation: Deviation of the displayed value in relation to the real measurement value.
Measurement rate: Number of measurements which a device performs in a precise time interval.
Measurement uncertainty: It indicates the range in which the real measured value is.
Measurement range: Range used by meters. When both upper and lower limits are exceeded there is measurement values.
Go to the top
Over oscillation: A sudden change of the input signal which always brings that the back regulation exceeds the output signal before reaching the desired value. This process is called over oscillation.
Go to the top
Profibus DP: For the control and consultation of sensors and actuators.
Go to the top
RS-232 interface: refer to “Connection port”.
Recalibration: periodical measurement of the method of measurement
or control, to test its correction.
Repeatability: (standard deviation) the coincidence of repeated measurements under the same conditions.
Resolution: The smallest separation in the magnitude that the meter can detect, it is also known as digit.
Regulator: Unit which controls an input signal which depends on an output signal.
Response time: Time interval from the moment a magnitude is connected to a meter to the moment in which this value is displayed.
Response time: It is the time that a controller needs to introduce the output magnitude inside the established magnitude.
Go to the top
Scale: The conversion of a standard signal in a physical quantity is known as scale.
Signal converters: Unit for the conversion of physical, chemical or biological quantities into a standard electrical signal.
Standard signal: Standard electrical signal in the control systems for the transference of physical, chemical or biological measurement values, i.e. 4-20 mA.
Sensors: Unit for the conversion of physical, chemical or biological quantities in an electrical magnitude to be detected by electronic regulators.
Go to the top
Thermal influence: This is physically tied and it can only be corrected by means of incorporated compensations. Some meters have an automatic temperature compensation, others a mechanic one. The mechanic compensation shows the current temperature, for instance, by means of an adjusting wheel or a display.
Traceability: This concept describes a process through a measured value can be compared to the national standard of the magnitude. Thanks to the contract with the “CEM” and the DIN EN 45001 standard, it is not necessary to show the retrievability.
Tolerance of a measuring device: each device has an indicated tolerance to physical conditions. tolerance defines the most deviation allowed.
Totalizer: This functions allows for the integration of the measurement values through time.
Go
to the top
UKAS: The United Kingdom Accreditation Service is the sole national accreditation body recognised by government to assess, against internationally agreed standards, organisations that provide certification, testing, inspection and calibration services. Testing Laboratories, Calibration Laboratories, Certification Bodies, Inspection Bodies, Proficiency Testing Providers, Reference Material Producers, Medical Laboratories (UKAS)
Go to the top
Validation: document demonstrating that a process is more appropriate for performing a tare.
Go to the top
Final note:
The information presented here may not be complete or exact. It is provided simply as a guide in realtion to measuring equipment. The pages within the domain www.industrial-needs.com are property of PCE Holding (©), Germany.
|
