Voltage converter PCE-P20Z for alternating voltage The PCE-P20Z voltage transmitter measures voltages up to 600 V AC and converts this into a standard signal. Depending on the version, the voltage converter PCE-P20Z can measure voltages up to 250 V AC, 400 V AC or 600 V AC and outputs a 4 ... 20 mA standard signal. Depending on the model, the supply voltage of the transmitters is either 85 ... 253 V AC / DC or 20 ... 40 V AC / DC. The installation is simple: the voltage transmitter can be easily attached to a 35 mm DIN rail. The standard signals output by the measuring transducer can then be processed with the aid of controllers or screen recorders.
Highlights
- RMS Measurement of voltages up to 600 V AC
- Output: 4 ... 20 mA Standard signal
- Various supply voltages
- Compact DIN rail mounting
- IP 50
- Current transformer connectable
- Easy to operate
Specification
|
Technical specifications
|
| Inputs (max) |
100 VAC
250 VAC
400 VAC
600 VAC
|
| Accuracy class |
0.2 |
| frequency |
45 ... 500 Hz |
| exit |
4 ... 20 mA
0 ... 10V |
| Dimensions |
22.5 mm x 120 mm x 100 mm / 0.8 x 4.7 x 3.9 in |
| Assembly |
DIN rail mounting 35 mm |
| Protection class |
IP 50 |
| Supply voltage |
85 ... 253 V AC / DC
20 ... 40 V AC / DC
|
| Power consumption |
4 VA |
| Environmental conditions |
-20 ... +55 °C / -4 ... 131 °F / <95% rh |
| Maximum cable cross section |
1.5 mm² |
Delivery Scope
Delivery Scope
1 x Voltage transmitter PCE-P20Z AC Voltage
1 x User manual
