Heat Pump Test Equipment

Pressure Gauge PCE-HVAC 10
₹36,590.00
Price excl. VAT &. delivery
2 year Warranty
The pressure gauge is a robust measuring instrument designed for daily use in refrigeration systems and heat pumps to determine pressure and temperature. Measurement with the pressure gauge is carried out using supplied refrigerant hoses and 2 NTC clamp-on temperature sensors. The 83 preloaded refrigerants can be quickly selected and are visible on the measurement screen.

  • Measurement Range: -1 … +60 bar
  • Resolution: 0.01 bar
  • Accuracy: ±0.5% F.S. (Full Scale)
  • 83 refrigerants stored in the device
  • 2-way valve block with 3 connectors 7/16" – UNF
  • Includes 2 NTC clamp-on temperature sensors
  • Temperature measurement -10 … +200 °C
Pyrometer PCE-TC 30N
₹112,627.00
Price excl. VAT &. delivery
2 year Warranty
The PCE-TC 30N pyrometer for preventive maintenance is the ideal tool for maintenance and servicing. This pyrometer is a must-have for electricians, fitters or general maintenance personnel for troubleshooting and fault prevention of electrical equipment, electromechanical devices, production process machinery, heating, ventilation and air conditioning systems, especially when working in harsh environments.

  • IR resolution: 160 x 120 pixels
  • Measuring range: -20 … 450°C / -4  … 842°F
  • Thermal sensitivity: 70 mK
  • Memory: 3 GB memory for more than 20,000 pictures
  • 5 different color palettes
  • Hot and cold spot location
  • Picture in Picture function
Pyrometer PCE-TC 30N-ICA incl. ISO Calibration Certificate
₹148,785.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration
The PCE-TC 30N pyrometer for preventive maintenance is the ideal tool for maintenance and servicing. This pyrometer is a must-have for electricians, fitters or general maintenance personnel for troubleshooting and fault prevention of electrical equipment, electromechanical devices, production process machinery, heating, ventilation and air conditioning systems, especially when working in harsh environments.

  • IR resolution: 160 x 120 pixels
  • Measuring range: -20 … 450°C / -4  … 842°F
  • Thermal sensitivity: 70 mK
  • Memory: 3 GB memory for more than 20,000 pictures
  • 5 different color palettes
  • Hot and cold spot location
  • Picture in Picture function
  • incl. ISO Calibration Certificate
Pyrometer PCE-ILD 10
₹21,264.00
Price excl. VAT &. delivery
2 year Warranty

The pyrometer has a measuring range of -50 … +500 °C and an adjustable emission value between 0.10 … 1.00. In addition to the current reading, the largest, smallest, average and differential reading can be displayed.

  • Measuring range: -50 … 500 °C / -58 … 932 °F
  • Resolution: 0.1°C
  • Accuracy: ±3 °C / ±5.4 °F at -50 … 20 °C / -58 … 68 °F
  • Spot ratio: 12:1
  • Multipoint laser

Digital Thermometer PCE-TC 33N
₹115,603.00
Price excl. VAT &. delivery
2 year Warranty
In preventative maintenance, the high-resolution PCE-TC 33N digital thermometer is ideal for maintaining or repairing machinery or other equipment. The heart of the high-resolution digital thermometer PCE-TC 33N is an uncooled microbolometer (uncooled focal plane array) with a resolution of 220 x 160 pixels.

  • IR resolution: 220 x 160 pixels
  • Measuring range: -20 … 300°C / -4  … 572°F
  • Thermal sensitivity: 70 mK
  • Memory: 3 GB memory for more than 20,000 pictures
  • 5 different color palettes
  • Hot and cold spot location
  • Picture in Picture function
Digital Thermometer PCE-TC 33N-ICA incl. ISO Calibration Certificate
₹154,737.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration
In preventative maintenance, the high-resolution PCE-TC 33N digital thermometer is ideal for maintaining or repairing machinery or other equipment. The heart of the high-resolution digital thermometer PCE-TC 33N is an uncooled microbolometer (uncooled focal plane array) with a resolution of 220 x 160 pixels.

  • IR resolution: 220 x 160 pixels
  • Measuring range: -20 … 300°C / -4  … 572°F
  • Thermal sensitivity: 70 mK
  • Memory: 3 GB memory for more than 20,000 pictures
  • 5 different color palettes
  • Hot and cold spot location
  • Picture in Picture function
  • incl. ISO Calibration Certificate
Ultrasonic Leak Detector PCE-LDC 8
₹242,529.00
Price excl. VAT &. delivery
2 year Warranty
The Ultrasonic Leak Detector is used to locate leaks on compressed air lines. Furthermore, the Ultrasonic Leak Detector can also be used on coolant lines or gas lines for leak detection.

  • Measuring principle: ultrasound
  • Measuring principle: air, coolant, non-explosive gases
  • Working frequency of 40 kHz
  • up to 6 h battery operation
  • Leak detection via headphones and LCD display
  • Localize leaks up to 18m, 59 ft.
Infrared Imaging Camera PCE-TC 28
₹91,646.00
Price excl. VAT &. delivery
2 year Warranty

The infrared imaging camera was designed for taking non-contact temperature measurements. To get accurate readings, the emissivity of the infrared imaging camera can be adjusted, depending on the operation purpose. Besides taking infrared images, the infrared imaging camera can also take normal pictures, as well as a mixture of both, due to the built-in digital camera.


  • Measurement range: -20 … +600°C / -4 … 1112°F
  • Accuracy: ± 2%, ± 2°C / 3.6°F
  • Frequency image recording: 9 Hz
  • Camera: 32 x 31 Pixel

Infrared Imaging Camera PCE-TC 28-ICA incl. ISO Calibration Certificate
₹126,912.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration

The infrared imaging camera was designed for taking non-contact temperature measurements. To get accurate readings, the emissivity of the infrared imaging camera can be adjusted, depending on the operation purpose. Besides taking infrared images, the infrared imaging camera can also take normal pictures, as well as a mixture of both, due to the built-in digital camera.


  • Measurement range: -20 … +600°C / -4 … 1112°F
  • Accuracy: ± 2%, ± 2°C / 3.6°F
  • Frequency image recording: 9 Hz
  • Camera: 32 x 31 Pixel- incl. ISO Calibration Certificate

Manometer PCE-932
₹39,120.00
Price excl. VAT &. delivery
2 year Warranty

PCE-932 is an easy-to-use, digital, handheld device for high pressure measurement in hydraulic and compressor systems, pumps, tanks and silos in chemical, manufacturing, plastics and HVAC industries. This portable pressure measuring device can be connected to pressure sensors with ranges up to 400 bar (each with a 1.2 m / 3.9 ft connecting cable). Please note: Pressure sensors are sold separately.


  • Measuring range: 0 to 400 bar / 0 to 5801 psi, depending on sensor
  • Measures system pressure in all media (e.g., gasses, liquids, etc.)
  • Offers min, max and hold functionality

Temperature Meter PCE-TC 32N
₹144,321.00
Price excl. VAT &. delivery
2 year Warranty
The temperature meter has a measuring range of -20 … +550 °C. This means that the temperature meter already covers a wide temperature range of measuring tasks. With a frame rate of 25 Hz, problems can be quickly localised with the temperature gauge.

  • Measuring range: -20 … +550 °C
  • Picture-in-picture function
  • Frame rate: 25 Hz
  • Internal/external memory
  • Wi-Fi 802.11
  • Display resolution: 240 x 320 pixels
  • Battery
Temperature Meter PCE-TC 32N-ICA incl. ISO Calibration Certificate
₹182,563.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration
The temperature meter has a measuring range of -20 … +550 °C. This means that the temperature meter already covers a wide temperature range of measuring tasks. With a frame rate of 25 Hz, problems can be quickly localised with the temperature gauge.

  • Measuring range: -20 … +550 °C
  • Picture-in-picture function
  • Frame rate: 25 Hz
  • Internal/external memory
  • Wi-Fi 802.11
  • Display resolution: 240 x 320 pixels
  • Battery
    - incl. ISO Calibration Certificate
Thermal Imaging Camera PCE-TC 34N
₹163,814.00
Price excl. VAT &. delivery
2 year Warranty

The thermal imaging camera has a resolution of 320 x 240 pixels. With a measuring range of -20 … 300 °C, the thermal imaging camera already covers a large temperature range. The emission value of the thermal imaging camera can be set to carry out measurements on different surfaces.

  • Measuring range: -20 … 300 °C / -4 … 572 °F
  • Infrared and real image resolution: 320 x 240 pixels
  • Picture in picture function
  • USB-C interface
  • Refresh rate: 9Hz
  • Storage for about 20,000 images

Thermal Imaging Camera PCE-TC 34N-ICA incl. ISO Calibration Certificate
₹202,651.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration

The thermal imaging camera has a resolution of 320 x 240 pixels. With a measuring range of -20 … 300 °C, the thermal imaging camera already covers a large temperature range. The emission value of the thermal imaging camera can be set to carry out measurements on different surfaces.

  • Measuring range: -20 … 300 °C / -4 … 572 °F
  • Infrared and real image resolution: 320 x 240 pixels
  • Picture in picture function
  • USB-C interface
  • Refresh rate: 9Hz
  • Storage for about 20,000 images
  • incl. ISO Calibration Certificate

Thermometer PCE-T 420 4-channel
₹58,315.00
Price excl. VAT &. delivery
2 year Warranty
High Accuracy
The 4-channel thermometer allows for the display and archiving of multiple temperature sensors simultaneously. It can be connected to up to 8 different types of thermocouples.

  • Measurement range from -200 … +1800 °C
  • High resolution of ± (0.04% of full scale + 0.3 K) for Type K
  • Connectable with 8 types of thermocouples
  • Thermocouple types: K, J, S, R, E, T, N, B
  • Storage for 10 million measurement values
  • Adjustable alarm limits
  • Equipped with 4 channels
Thermometer 4-channel PCE-T 420 incl. ISO-Calibration Certificate
₹67,243.00
Price excl. VAT &. delivery
2 year Warranty
High Accuracy ISO Calibration
The 4-channel thermometer allows for the display and archiving of multiple temperature sensors simultaneously. It can be connected to up to 8 different types of thermocouples.

  • Measurement range from -200 … +1800 °C
  • High resolution of ± (0.04% of full scale + 0.3 K) for Type K
  • Connectable with 8 types of thermocouples
  • Thermocouple types: K, J, S, R, E, T, N, B
  • Storage for 10 million measurement values
  • Adjustable alarm limits
  • Equipped with 4 channels
  •  incl. ISO-Calibration Certificate
Clamp Meter PCE-CTI 10
₹55,190.00
Price excl. VAT &. delivery
2 year Warranty

The clamp meter is the ideal measuring device for measuring voltages up to 1500 V AC/DC and currents up to 1000 A AC/DC. The current measurement with the clamp meter is inductive. To do this, the supply line is placed in the clamp meter.

  • Measuring range: 0 … 1500 V AC/DC
  • Free app for Android and iOS
  • Data logging for up to 100,000 measured values
  • Inrush current measurement
  • Insulation categories: CAT IV 600 V, CAT III 1000 V, CAT II 1500 V

Clamp Meter PCE-CTI 10-ICA incl. ISO Calibration Certificate
₹65,457.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration

The clamp meter is the ideal measuring device for measuring voltages up to 1500 V AC/DC and currents up to 1000 A AC/DC. The current measurement with the clamp meter is inductive. To do this, the supply line is placed in the clamp meter.

  • Measuring range: 0 … 1500 V AC/DC
  • Free app for Android and iOS
  • Data logging for up to 100,000 measured values
  • Inrush current measurement
  • Insulation categories: CAT IV 600 V, CAT III 1000 V, CAT II 1500 V
  • incl. ISO Calibration Certificate
