Power Meter

Power Meter PCE-PA 7200
₹97,598.00
Price excl. VAT &. delivery
2 year Warranty
Topseller
The power meter is a useful tool for the precise measurement of various electrical parameters. With a measuring range of up to 9999 kW for power and 0 to 1000 A for alternating current, it offers sufficient flexibility for various applications. The power meter offers a memory for 2000 measured values and data transfer to the software included in the scope of delivery.

  • AC voltage: 0 … 600 V
  • Resolution 0.1 V
  • Accuracy ±1 % of Mw. ±5 digits
  • Alternating current: 0 … 1000 A
  • Resolution 0.1 A
  • Accuracy 1.5 % v.Mw.
  • Active power
  • Power factor
  • Active energy
  • Frequency
  • Adjustable alarms
  • Memory and software
Power Meter 2-Channel PCE-PA 7500
₹212,769.00
Price excl. VAT &. delivery
2 year Warranty
The power meter is used for the quick and precise measurement or analysis of parameters such as power consumption and quality. The power meter has 2 input channels for measuring parameters including voltage, current, active power, power factor, frequency, and energy consumption in kWh.

  • Power range: 0.1 … 5000 W
  • Current range: 0.001 … 20 A AC
  • Frequency, power factor, energy
  • Accuracy: ±(0.4% of reading + 0.1)
  • 2 input channels
  • Color display
Power Meter PCE-PA 8000
₹241,786.00
Price excl. VAT &. delivery
2 year Warranty
Topseller

PCE-PA 8000 is a portable handheld Power Meter used for the testing and inspection of 3-phase / 4-wire, 3-phase / 3-wire, 1-phase / 2-wire and 1-phase / 3-wire electrical circuits. This handy power quality analyzer not only measures multiple electrical properties in real time, but also saves the measurement data in .xls format to the included SD card memory for quick and easy data transfer and analysis using Microsoft Excel.

  • True RMS measurement for ACA, ACV
  • True power: W, KW, MW
  • VA, KVA, MVA, VAR, KVAR, MVAR
  • PF (power factor), phase angle (Φ)
  • KWH, KVAH, KVARH, PFH
  • Voltage measurement range: 10 … 600 ACV
  • Current measurement range: 0.2 … 1200 ACA
  • Real-time current, voltage and power consumption measurement
  • Built-in data recorder with adjustable sample rate: 2 … 7,200 sec.

Power Meter 2-Channel PCE-PA 7500-ICA incl. ISO-Calibration Certificate
₹276,307.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration
The power meter is used for the quick and precise measurement or analysis of parameters such as power consumption and quality. The power meter has 2 input channels for measuring parameters including voltage, current, active power, power factor, frequency, and energy consumption in kWh.

  • Power range: 0.1 … 5000 W
  • Current range: 0.001 … 20 A AC
  • Frequency, power factor, energy
  • Accuracy: ±(0.4% of reading + 0.1)
  • 2 input channels
  • Color display
  • incl. ISO-Calibration Certificate
Power Meter PCE-PA 8500 HP
₹488,644.00
Price excl. VAT &. delivery
2 year Warranty
Topseller
The power meter redefines the standards in electrical measurement technology and offers a comprehensive range of functions for precise and detailed measurements. The power meter enables accurate measurements of electrical voltage, current, frequency, harmonics, harmonic and starting currents. In addition, precise power and energy measurements can be made, enabling accurate monitoring and optimisation of energy consumption.

  • Voltages: 1 … 1000 V
  • Current: 1 … 1500 A AC
  • Graphical representation of the
      waveform and vector graphics
  • Data logger with 8 GB memory
  • LAN and USB data interface
  • incl. flexible current clamps
  • Test standards:
    IEC61000-4-30, 61000-4-15, 61000-4-7, EN50160
Power Meter PCE-GPA 50
₹113,222.00
Price excl. VAT &. delivery
2 year Warranty
The PCE-GPA 50 power meter is used to measure the current of 1- or 3-phase loads. This power meter is particularly characterized by its measuring range up to 2000 A. Another highlight is the graphic display of the power meter.

Measurement functions
  • AC voltage AC V
  • AC AC
  • Power factor (PF)
  • Phase angle
  • Frequency
  • Active, reactive and apparent power
  • Harmonic AC V
  • AC
  • Harmonic AC V%
  • Absolute harmonic distortion
  • Temperature type K thermocouple
Power Meter PCE-GPA 50-ICA incl. ISO Calibration Certificate
₹143,577.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration
The PCE-GPA 50 power meter is used to measure the current of 1- or 3-phase loads. This power meter is particularly characterized by its measuring range up to 2000 A. Another highlight is the graphic display of the power meter.

Measurement functions
  • AC voltage AC V
  • AC AC
  • Power factor (PF)
  • Phase angle
  • Frequency
  • Active, reactive and apparent power
  • Harmonic AC V
  • AC
  • Harmonic AC V%
  • Absolute harmonic distortion
  • Temperature type K thermocouple
  • incl. ISO Calibration Certificate
Power Meter PCE-PA 5500
₹19,180.00
Price excl. VAT &. delivery
2 year Warranty
The power meter is a compact instrument for measuring and displaying various grid parameters in three-phase grids. This power meter can record the energy values of individual consumers or electrical feeders. In addition to the voltages and currents, the apparent, reactive and active power as well as the active and reactive energy are measured and shown on the 68 x 55 mm display.

  • AC voltage: 30 … 264 V
  • Alternating current direct: 0.025 mA … 5 A
  • Energy meter
  • Harmonics up to the 50th order
  • RS485 Modbus interface
  • Accuracy class: 0.5
Power Meter PCE-PA6000
₹81,825.00
Price excl. VAT &. delivery
2 year Warranty

The power meter PCE-PA6000 power analyzer can be used as a desktop or portable instrument for measuring active power, apparent power, power factor, energy consumption, AC voltage, AC current, DC voltage, DC current, resistance and frequency. The power / performance measurement can be performed with this power analyzer either directly with the supplied test leads, or indirectly by current clamps.


  • Performance
  • Power factor
  • AC voltage and current- DC voltage and current, resistance and frequency
  • Incl. Data Cable and Test Leads
  • Software available in the accessories tab

Power Meter PCE-GPA 62
₹142,387.00
Price excl. VAT &. delivery
2 year Warranty

The Power Meter PCE-GPA 62 (Graphic Power Quality Analyzer) with network analyzer / power and energy meter with data logger. The one-phase harmonic Analyzer (Graphic Power Quality Analyzer) is used for single-phase or three-phase measurements of active, reactive and apparent power, power factor, phase angle, energy, voltage, current as well as peaks and harmonics. This clamp meter is a perfect tool for all energetic measurements. It is delivered manufacturer calibrated and can be certified to ISO or standards.

  • Real-time test, register and measurement of voltage and current (real and effective)
  • Measures power factor and phase angle, frequency, energy, active, reactive and apparent power   (single-phase or three-phase in symmetrical networks).
  • Max. conductor diameter: 55 mm / 2.2 in
  • Records up to 50,000 records


Power Meter PCE-PA6000-ICA incl. ISO Calibration Certificate
₹130,929.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration

The Power Meter PCE-PA6000 power analyzer can be used as a desktop or portable instrument for measuring active power, apparent power, power factor, energy consumption, AC voltage, AC current, DC voltage, DC current, resistance and frequency. The power / performance measurement can be performed with this power analyzer either directly with the supplied test leads, or indirectly by current clamps.


  • Performance
  • Power factor
  • AC voltage and current
  • DC voltage and current, resistance and frequency
  • Incl. Data Cable and Test Leads
  • Software available in the accessories tab
  • Incl. ISO Calibration Certificate

Power Meter PCE-GPA 62-ICA incl. ISO Calibration Certificate
₹161,136.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration

This Power Meter is used for single-phase or three-phase measurements of the active, reactive and apparent power, power factor, phase angle, energy, voltage, current as well as peaks and harmonics up to 50º of the harmonic waveform. The power analyzer clamp is equipped with data logger. The test instrument is delivered manufacturer ISO calibrated.


  • Real-time test, register and measurement of voltage and current (real and effective)
  • Measures power factor and phase angle, frequency, energy, active, reactive and apparent power   (single-phase or three-phase in symmetrical networks).
  • Max. conductor diameter: 55 mm / 2.2 in
  • Records up to 50,000 records
  • incl. ISO Calibration Certificate

Power Meter PCE-360
₹249,225.00
Price excl. VAT &. delivery
2 year Warranty

The PCE-360 is a Single-Phase Power Meter with data logger functionality. This versatile power analyzer can take single-phase and three-phase power measurements both in real time and over an extended time period.


  • Measuring range: 10 … 999.9 V
  • AC voltage AC
  • Alternating current AC
  • Active power
  • Power factor
  • Phase angle
  • Frequency
  • Harmonic measurement
  • Data memory: 512 kB   (non-volatile memory)
  • incl. 4 current clamps / tapping terminals
  • Standards: IP 30 / IEC 61 010, 600 V / CAT III
  • incl. ISO Calibration Certificate

Power Meter PCE-360-ICA incl. ISO Calibration Certificate
₹294,163.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration

The PCE-360 is a HVAC Meter with data logger functionality. This versatile power analyzer can take single-phase and three-phase power measurements both in real time and over an extended time period.


  • Measuring range: 10 … 999.9 V
  • AC voltage AC
  • Alternating current AC
  • Active power
  • Power factor
  • Phase angle
  • Frequency
  • Harmonic measurement
  • Data memory: 512 kB   (non-volatile memory)
  • incl. 4 current clamps / tapping terminals
  • Standards: IP 30 / IEC 61 010, 600 V / CAT III
  • incl. ISO Calibration Certificate
  • incl. ISO Calibration Certificate

Power Meter PCE-830-1
₹356,659.00
Price excl. VAT &. delivery
2 year Warranty

The PCE-830 Power Meter is used for measuring one to three phases of electrical quantities for alternating current (AC). This Power Meter also measures parameters such as voltage, current, frequency, harmonics, and power as well as indicating, according to standard EN50160, harmonic values, interharmonics, and asymmetrics. Interference, such as interruptions, leaks, overloads, or transience (from 16 µs) are detected with their corresponding values. The power logging instrument is delivered manufacturer calibrated. An ISO calibration certificate may be ordered optionally.


  • PCE-830 + PCE-6801 amp clamp (100 A)
  • Electrical conductor pick-up: 30 mm / 1.1 in diameter
  • Range selection: manual (1 A, 10 A, 100 A)
  • Clamp dimensions: 210 mm x 62 mm x 36 mm / 8.2 in x 2.4 in x 1.4 in
  • Sampling rate: 2 sec.
  • Memory size: 512 kB (max. 52,000 values (single phase)

Power Meter PCE-830-1-ICA incl. ISO Calibration Certificate
₹427,785.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration

The PCE-830 Power Meter is used for measuring one to three phases of electrical quantities for alternating current (AC). This 3-Phase Power Meter also measures such parameters as voltage, current, frequency, harmonics and power as well as indicating, according to standard EN50160, harmonic values, interharmonics and asymmetrics. Interference, such as interruptions, leaks, overloads or transience (from 16µs) are detected with their corresponding values.


  • PCE-830 + PCE-6801 amp clamp (100 A)
  • Electrical conductor pick-up: 30 mm diameter
  • Range selection: manual (1 A, 10 A, 100 A)
  • Clamp dimensions: 210 x 62 x 36 mm
  • Incl. ISO calibration certificate

Power Meter PCE-830-2
₹401,745.00
Price excl. VAT &. delivery
2 year Warranty

The PCE-830-2 Power Meter is used for measuring one to three phases of electrical quantities for alternating current (AC). This Power Meter also measures parameters such as voltage, current, frequency, harmonics, and power as well as indicating, according to standard EN50160, harmonic values, interharmonics, and asymmetrics. Interference, such as interruptions, leaks, overloads, or transience (from 16 µs) are detected with their corresponding values. The power logging instrument is delivered manufacturer calibrated. An ISO calibration certificate may be ordered optionally.


  • PCE-830 + PCE-6802 amp clamp (1000 A)
  • Electrical conductor pick-up: 55 mm / 2.1 in diameter
  • Range selection: manual (10 A, 100 A, 1000 A)
  • Clamp dimensions: 244 mm x 97 mm x 46 mm / 9.6 in x 3.7 in x 1.8 in
  • Sampling rate: 2 sec.
  • Memory size: 512 kB (max. 52,000 values (single phase)

Power Meter PCE-830-2-ICA incl. ISO Calibration Certificate
₹473,169.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration

The PCE-830 Power Meter is used for measuring one to three phases of electrical quantities for alternating current (AC). This Power Meter also measures such parameters as voltage, current, frequency, harmonics and power as well as indicating, according to standard EN50160, harmonic values, interharmonics and asymmetrics. Interference, such as interruptions, leaks, overloads or transience (from 16µs) are detected with their corresponding values.


  • PCE-830 + PCE-6802 amp clamp (1000 A)
  • Electrical conductor pick-up: 55 mm / 2.2 in diameter
  • Range selection: manual (10 A, 100 A, 1000 A)
  • Clamp dimensions: 244 x 97 x 46 mm / 9.6 x 3.8 x 1.8 in
  • Incl. ISO calibration certificate
