Power Quality Analyser / Power Analyzer

Power Analyzer PCE-PA 7200
₹97,598.00
Price excl. VAT &. delivery
2 year Warranty
Topseller
The power analyzer is a useful tool for the precise measurement of various electrical parameters. With a measuring range of up to 9999 kW for power and 0 to 1000 A for alternating current, it offers sufficient flexibility for various applications. The power analyzer offers a memory for 2000 measured values and data transfer to the software included in the scope of delivery.

  • AC voltage: 0 … 600 V
  • Resolution 0.1 V
  • Accuracy ±1 % of Mw. ±5 digits
  • Alternating current: 0 … 1000 A
  • Resolution 0.1 A
  • Accuracy 1.5 % v.Mw.
  • Active power
  • Power factor
  • Active energy
  • Frequency
  • Adjustable alarms
  • Memory and software
Power Analyzer 2-Channel PCE-PA 7500
₹212,769.00
Price excl. VAT &. delivery
2 year Warranty
The power analyzer is used for the quick and precise measurement or analysis of parameters such as power consumption and quality. The power meter has 2 input channels for measuring parameters including voltage, current, active power, power factor, frequency, and energy consumption in kWh.

  • Power range: 0.1 … 5000 W
  • Current range: 0.001 … 20 A AC
  • Frequency, power factor, energy
  • Accuracy: ±(0.4% of reading + 0.1)
  • 2 input channels
  • Color display
Power Analyzer PCE-PA 8000
₹241,786.00
Price excl. VAT &. delivery
2 year Warranty
Topseller

PCE-PA 8000 is a portable handheld power analyzer used for the testing and inspection of 3-phase / 4-wire, 3-phase / 3-wire, 1-phase / 2-wire and 1-phase / 3-wire electrical circuits. This handy power quality analyzer not only measures multiple electrical properties in real time, but also saves the measurement data in .xls format to the included SD card memory for quick and easy data transfer and analysis using Microsoft Excel.

  • True RMS measurement for ACA, ACV
  • True power: W, KW, MW
  • VA, KVA, MVA, VAR, KVAR, MVAR
  • PF (power factor), phase angle (Φ)
  • KWH, KVAH, KVARH, PFH
  • Voltage measurement range: 10 … 600 ACV
  • Current measurement range: 0.2 … 1200 ACA
  • Real-time current, voltage and power consumption measurement
  • Built-in data recorder with adjustable sample rate: 2 … 7,200 sec.

Power Analyzer 2-Channel PCE-PA 7500-ICA incl. ISO-Calibration Certificate
₹276,307.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration
The power analyzer is used for the quick and precise measurement or analysis of parameters such as power consumption and quality. The power meter has 2 input channels for measuring parameters including voltage, current, active power, power factor, frequency, and energy consumption in kWh.

  • Power range: 0.1 … 5000 W
  • Current range: 0.001 … 20 A AC
  • Frequency, power factor, energy
  • Accuracy: ±(0.4% of reading + 0.1)
  • 2 input channels
  • Color display
  • incl. ISO-Calibration Certificate
Power Analyzer PCE-PA 8500 HP
₹488,644.00
Price excl. VAT &. delivery
2 year Warranty
Topseller
The power analyzer redefines the standards in electrical measurement technology and offers a comprehensive range of functions for precise and detailed measurements. The power analyzer enables accurate measurements of electrical voltage, current, frequency, harmonics, harmonic and starting currents. In addition, precise power and energy measurements can be made, enabling accurate monitoring and optimisation of energy consumption.

  • Voltages: 1 … 1000 V
  • Current: 1 … 1500 A AC
  • Graphical representation of the
      waveform and vector graphics
  • Data logger with 8 GB memory
  • LAN and USB data interface
  • incl. flexible current clamps
  • Test standards:
    IEC61000-4-30, 61000-4-15, 61000-4-7, EN50160
Power Analyzer PCE-PA 8300-1
₹445,939.00
Price excl. VAT &. delivery
2 year Warranty

The easy-to-use PCE-PA 8300 Three Phase Power Data Logger is the ideal tool for performing power and harmonics analysis as well as for measuring network capacity. The PCE-PA 8300 is a 3-phase power analyzer that features:


  • Voltage measurement range of 10 V … 600 V AC
  • Current measurement range of (Set 1) 20 A … 1200 A AC
  • Performance measurement range of 0 kW … 9.999 MW (VA/VAR)
  • Simultaneous display of harmonics and waveform
  • Graphic Phasor diagram
  • Captures transients including dip, swell, and outage

Power Analyzer PCE-PA 8300-2
₹462,753.00
Price excl. VAT &. delivery
2 year Warranty

The easy-to-use PCE-PA 8300 Three Phase Power Data Logger is the ideal tool for performing power and harmonics analysis as well as for measuring network capacity. The PCE-PA 8300 is a 3-phase power analyzer that features:


  • Voltage measurement range of 10 V … 600 V AC
  • Current measurement range of (Set 2) 30 A … 3000 A AC
  • Performance measurement range of 0 kW … 9.999 MW (VA/VAR)
  • Simultaneous display of harmonics and waveform
  • Graphic Phasor diagram
  • Captures transients including dip, swell, and outage

Power Quality Analyzer PCE-360
₹249,225.00
Price excl. VAT &. delivery
2 year Warranty

The PCE-360 is a Single-Phase Power Meter with data logger functionality. This versatile power analyzer can take single-phase and three-phase power measurements both in real time and over an extended time period.


  • Measuring range: 10 … 999.9 V
  • AC voltage AC
  • Alternating current AC
  • Active power
  • Power factor
  • Phase angle
  • Frequency
  • Harmonic measurement
  • Data memory: 512 kB   (non-volatile memory)
  • incl. 4 current clamps / tapping terminals
  • Standards: IP 30 / IEC 61 010, 600 V / CAT III
  • incl. ISO Calibration Certificate

Power Analyzer PCE-GPA 62
₹142,387.00
Price excl. VAT &. delivery
2 year Warranty

This power analyzer is used for single-phase or three-phase measurements of the active, reactive and apparent power, power factor, phase angle, energy, voltage, current as well as peaks and harmonics up to 50º of the harmonic waveform. The power analyzer clamp is equipped with data logger. The test instrument is delivered manufacurer calibrated (ISO or certification as an option).


  • Real-time test, register and measurement of voltage and current (real and effective)
  • Measures power factor and phase angle, frequency, energy, active, reactive and apparent power   (single-phase or three-phase in symmetrical networks).
  • Max. conductor diameter: 55 mm / 2.2 in
  • Records up to 50,000 records


Power Analyzer PCE-GPA 62-ICA incl. ISO Calibration Certificate
₹161,136.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration

This power analyzer is used for single-phase or three-phase measurements of the active, reactive and apparent power, power factor, phase angle, energy, voltage, current as well as peaks and harmonics up to 50º of the harmonic waveform. The power analyzer clamp is equipped with data logger. The test instrument is delivered manufacturer calibrated (ISO or certification as an option).


  • Real-time test, register and measurement of voltage and current (real and effective)
  • Measures power factor and phase angle, frequency, energy, active, reactive and apparent power   (single-phase or three-phase in symmetrical networks).
  • Max. conductor diameter: 55 mm / 2.2 in
  • Datalogger for 50,000 readings / software/ USB interface
  • incl. ISO Calibration Certificate

Power Analyzer PCE-360-ICA incl. ISO Calibration Certificate
₹294,163.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration

The PCE-360 is a HVAC Meter with data logger functionality. This versatile power analyzer can take single-phase and three-phase power measurements both in real time and over an extended time period.


  • Measuring range: 10 … 999.9 V
  • AC voltage AC
  • Alternating current AC
  • Active power
  • Power factor
  • Phase angle
  • Frequency
  • Harmonic measurement
  • Data memory: 512 kB   (non-volatile memory)
  • incl. 4 current clamps / tapping terminals
  • Standards: IP 30 / IEC 61 010, 600 V / CAT III
  • incl. ISO Calibration Certificate
  • incl. ISO Calibration Certificate

Power Analyzer PCE-PCM 1
₹29,745.00
Price excl. VAT &. delivery
2 year Warranty

PCE-PCM 1 is a multipurpose power analyzer used to measure alternating current (AC), voltage (TRMS) and frequency to determine active (kW), apparent (kVA) and reactive (kVAR) power as well as active energy (kWh) consumption. Both the phase angle and the power factor (cos φ) are shown on the handheld power meter's large and easy-to-read backlit display.

  • Voltage (50 … 200 Hz): 100 / 400 / 750V, ± (1.2% + 5 digits)
  • Internal memory: Stores up to 99 measurement values
  • Includes USB cable and PC software
  • Three-phase power measurement
  • True RMS

Power Analyzer PCE-PCM 3
₹35,102.00
Price excl. VAT &. delivery
2 year Warranty
Wireless
With the power analyzer AC currents of up to 1000 A AC can be measured easily. At the same time, voltages of up to 1000V AC / DC can be measured with the power analyzer.

Measuring function
  • Current measurement AC
  • Inrush current AC
  • Voltage measurement DC
  • Voltage measurement AC
  • Frequency measurement
  • Frequency measurement current measurement function
  • Frequency measurement voltage measurement function
  • Duty cycle
  • Resistance measurement
  • Continuity test
  • Capacity measurement
  • Diode measurement
  • Single-phase power measurement
  • Power factor capacitive / inductive
  • Harmonics measurement
Power Analyzer PCE-GPA 50
₹113,222.00
Price excl. VAT &. delivery
2 year Warranty
The PCE-GPA 50 power analyzer is used to measure the current of 1- or 3-phase loads. This power analyzer PCE-GPA 50 is particularly characterized by its measuring range up to 2000 A. Another highlight is the graphic display of the power analyzer.

Measurement functions
  • AC voltage AC V
  • AC AC
  • Power factor (PF)
  • Phase angle
  • Frequency
  • Active, reactive and apparent power
  • Harmonic AC V
  • AC
  • harmonic AC V%
  • Absolute harmonic distortion
  • Temperature type K thermocouple
Power Quality Analyser / Power Analyzer PCE-PA 6500 R11
₹119,025.00
Price excl. VAT &. delivery
2 year Warranty
The Power Quality Analyser / Power Analyzer measures current and voltage values using the connected current transformers and test leads. From this, the active, apparent and reactive power are determined and transmitted to the measuring platform every second via Wi-Fi. The data is then filed historically on the Power Quality Analyser / Power Analyzer, processed graphically and can be analysed or exported.

  • alternating voltage: 40 ... 400 V
  • alternating current: 0 ... 80 A
  • resolution: 0.01 V / 0.01 A
  • active, apparent and reactive power
  • electrical energy in Wh
  • incl. app for Android
  • 32 GB internal memory
  • magnetic measuring adaptor
Power Analyzer PCE-GPA 50-ICA incl. ISO Calibration Certificate
₹143,577.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration
The PCE-GPA 50 power analyzer is used to measure the current of 1- or 3-phase loads. This power analyzer is particularly characterized by its measuring range up to 2000 A. Another highlight is the graphic display of the power analyzer.

Measurement functions
  • AC voltage AC V
  • AC AC
  • Power factor (PF)
  • Phase angle
  • Frequency
  • Active, reactive and apparent power
  • Harmonic AC V
  • AC
  • Harmonic AC V%
  • Absolute harmonic distortion
  • Temperature type K thermocouple
  • incl. ISO Calibration Certificate
Power Quality Analyser / Power Analyzer PCE-PA 6500 F150
₹148,785.00
Price excl. VAT &. delivery
2 year Warranty
The Power Quality Analyser / Power Analyzer measures current and voltage values using the connected current transformers and test leads. From this, the active, apparent and reactive power are determined and transmitted to the measuring platform every second via Wi-Fi. The data is then filed historically on the Power Quality Analyser / Power Analyzer, processed graphically and can be analysed or exported.

  • alternating voltage: 40 ... 400 V
  • alternating current: 3 ... 4800 A
  • resolution: 0.01 V / 0.01 A
  • active, apparent and reactive power
  • electrical energy in Wh
  • incl. app for Android
  • 32 GB internal memory
  • magnetic measuring adaptor
Power Quality Analyser / Power Analyzer PCE-PA 6500 F50
₹148,785.00
Price excl. VAT &. delivery
2 year Warranty
The Power Quality Analyser / Power Analyzer measures current and voltage values using the connected current transformers and test leads. From this, the active, apparent and reactive power are determined and transmitted to the measuring platform every second via Wi-Fi. The data is then filed historically on the Power Quality Analyser / Power Analyzer, processed graphically and can be analysed or exported.

  • alternating voltage: 40 ... 400 V
  • alternating current: 2 ... 1250 A
  • resolution: 0.01 V / 0.01 A
  • active, apparent and reactive power
  • electrical energy in Wh
  • incl. app for Android
  • 32 GB internal memory
  • magnetic measuring adaptor
