The Surface Testing Colorimeter PCE-CSM 10 was developed for quality control, offers a high accuracy and comes with a 3.5" touch screen display. When using the Surface Testing Colorimeter, you can choose between different color spaces (CIE L*A*B, XYZ, Yxy, LCh, CIE LUV, HunterLAB). After a measurement with the Surface Testing Colorimeter, the reading can be used as a reference value while other readings can be recorded as a sample and later be compared to the reference value easily.
In addition to the individual color space coordinates, the deviation between the reading is also displayed. When using the Surface Testing Colorimeter, it is possible to store up to 1000 reference values and up to 15,000 samples on the device. The measured data can also be transferred to a PC via the USB interface. A special PC software is included in the package.
| General technical data | |
| Display type | TFT colour display |
| Display size | 3,5 Inch |
| Storage medium | Internal memory |
| Storage capacity | 25000 Values |
| Memory capacity (additional information) | 1000 standard values, 25000 samples |
| Interface | Mini-USB, RS232 |
| Sensor | Silicon photodiode |
| Light source | combined LED sources Illuminant: D65, A, C, D50, D55, D75, F1, F2(CWF), F3, F4, F5, F6, F7 (DLF), F8, F9, F10(TPL5), F11(TL84) F12(TL83/U30) |
| Measurement time | 1,2 s |
| Colour spaces | XYZ, Yxy, LCh, CIE LUV, HunterLAB, WI (whiteness), YI (yellowness) |
| Measuring aperature | Ø 8 mm |
| Measuring geometry | 8°/d |
| Wavelength range | 400 ... 700 Nm |
| Observer | 2°, 10° |
| Calibration | White or black calibration selectable |
| Colour difference | ΔE*ab ΔE*uv ΔE*94 ΔE*cmc (2:1) ΔE*cmc (1:1) ΔE*cmc (l:c) CIE2000 ΔE*00 ΔE (h) |
| Menu language | English, Chinese |
| Power supply | 3.7 V / 0.5 A |
| Connector type | Device-europlug |
| Capacity | 3200 mAh |
| Dimensions ( L x W x H ) | 230 x 90 x 77 mm |
| Weight | 600 g |
