Price excl. VAT &. delivery
2 year Warranty
Force range | 500 N / 50 kg / 110 lb |
Distance display resolution | 0.02 mm |
Travel path | 270 mm / 10.6" |
Speed | 1 ... 500 mm/min |
Resolution | 1 mm/min |
Speed accuracy |
2 % |
Power supply | 220 ... 240 V AC, 1.5 A |
Fuse | 2 A |
Ambient conditions | 20 °C ±10 °C, 15 ... 80 % RH |
Dimensions | 45 x 26 x 68 cm / 17.7 x 10.2 x 26.7" |
Weight | 35 kg / 77 lb |
Price excl. VAT &. delivery
2 year Warranty
The PCE-PFG force gauge is a handy, digital measuring device for measuring tensile and compressive forces. The force gauge offers a sampling rate of 500 Hz and various measurement options such as real-time measurement (RT), maximum value measurement (PEAK), configurable average value acquisition (Average) and automatic measurement storage of up to 100 measurements.
Price excl. VAT &. delivery
2 year Warranty
Digital force gauge PCE-DFG N 500 for tensile force measurement and pressure force measurement up to 500 N. The digital force gauge is for precise measurements with a resolution of 0.1 N.
