Universal Testing Machine

Universal Testing Machine PCE-HTS 50
₹248,630.00
Price excl. VAT &. delivery
2 year Warranty

The motorized tension-compression Universal Testing Machine is a motorized test station with a force range of up to 500 N. With the help of the horizontal Universal Testing Machine, it is possible to to carry out tension-compression tests.

  • Force range: 500 N / 50 kg / 110 lb
  • Distance display resolution: 0.02 mm
  • Resolution: 1 mm/min
  • Tensile and compression testing
  • Travel: 270 mm / 10.6"

Test Stand PCE-VTS 50
₹273,331.00
Price excl. VAT &. delivery
2 year Warranty

This vertical force test stand is a motorized test station with a force range of up to 500 N. In addition to setting the speed, the vertical force test stand also offers the option of switching between automatic and manual mode.

  • Force range: 500 N / 50 kg / 110 lb
  • Distance display resolution: 0.02 mm
  • Resolution: 1 mm/min
  • Tensile and compression testing
  • Travel: 270 mm / 10.6"
  • 220V AC ONLY

PCE-VTS 50-PFG 500-KIT incl. Force Test Stand and Force Gauge
₹303,091.00
Price excl. VAT &. delivery
2 year Warranty
The force gauge incl. test stand is a handy, digital measuring device for measuring tensile and compressive forces. The force gauge offers a sampling rate of 500 Hz and various measurement options such as real-time measurement (RT), maximum value measurement (PEAK), configurable average value acquisition (Average) and automatic measurement storage of up to 100 measurements. This kit contains a vertical materials test stand which is a motorized test station with a force range of up to 500 N.

  • Measuring range: 0 … 500 N
  • Resolution: 0.1 N
  • Accuracy: ± 0.3% of the measuring range
  • Memory for 100 measurements
  • USB interface
  • Graphic displayMotorised Force Test Stand PCE-VTS 50
  • Force range: 500 N / 50 kg / 110 lb
  • Distance display resolution: 0.02 mm
  • Resolution: 1 mm/min
  • Tensile and compression testing
  • Travel: 270 mm / 10.6"
  • 220V AC ONLY
Universal Testing Machine PCE-MTS500
₹323,923.00
Price excl. VAT &. delivery
2 year Warranty

Our universal testing machine PCE-MTS500 can be coupled and operated in a wide variety of versions with our force gauges, the PCE series. The universal testing machine lets you carry out almost all of your compression and tensile force applications with repeatability. The use of the universal testing machine offers the operator the most precise equality of test bench and sample.

  • Measuring range: max. 5000 N / 500 kg
  • Feed speed: 30 mm/min … 230 mm/min
  • All PCE devices adaptable
  • Robust steel design
  • ** N.B. The mounting plate ADP-UNI accessory must be ordered for internal load cell force gauges ***

PCE-VTS 50-DFG N 500-KIT incl. Force Test Stand and Force Gauge
₹370,051.00
Price excl. VAT &. delivery
2 year Warranty
Force test stand
The motorised force test stand can be used for vertical tensile and compressive force tests. All force gauges from PCE Instruments can be mounted on the force test stand (if necessary with an adapter plate). The force test stand can withstand a maximum load of 500 N.

  • Force range: max. 500 N / 50 kg / 110 lb
  • Travel path: max. 270 mm / 10.6"
  • Feed speed: 1 … 500 mm/min
  • Manual or automatic procedureForce gaugeDigital force gauge for tensile force measurement and compressive force measurement up to 500 N. The digital force gauge is for precise measurements with a resolution of 0.1 N.
  • Measuring range: 0 … 500 N
  • Accuracy: ± 0.1% of the measuring range
  • Tensile and compressive force measurement
  • 1600 Hz sampling rate
  • Interface: USB
  • 6 different measuring tips
  • Memory for 100 measurements
  • 220V AC ONLY
Universal Testing Machine PCE-MTS500-DFG N 5K-KIT
₹437,457.00
Price excl. VAT &. delivery
2 year Warranty

The universal testing machine measures both tensile forces and compressive forces and this with a very high resolution. The tensile force and the compressive force are often determined in the test laboratory, e.g. to determine the yield point, the tear-off force, the force required to operate a button or switch. The supplied motorized test stand can be coupled and operated in various versions with our force gauges.

Force Gauge PCE-DFG N 5K

  • Measuring range: 0 … 5000 N / 500 kg / 1100 lbs
  • Resolution: 1N / 0.22 lbs
  • Accuracy: ± 0.1% of the measuring range
  • Memory for 100 measurements
  • USB interface
  • Graphic displayTest Stand PCE-MTS500
  • Force range: max. 5000 N / 500 kg / 1100 lbs
  • Travel path: max. 300 mm / 11.8"
  • Feed speed: 30 mm/min … 230 mm/min / 1.18 … 9.05 in/min

Universal Testing Machine PCE-MTS500-FD 300 KIT
₹461,265.00
Price excl. VAT &. delivery
2 year Warranty

Our universal testing machine can be coupled and operated in a wide variety of versions with our force gauges, the PCE series. The universal testing machine lets you carry out almost all of your compression and tensile force applications with repeatability. The use of the universal testing machine offers the operator the most precise equality of test bench and sample.

  • Force range: max. 5000 N / 500 kg / 1100 lbs
  • Travel: max. 300 mm / 11.8"
  • Feed speed: 30 … 230 mm/min / 1.18 … 9.05 in/min
  • Manual or automatic procedure
  • incl. length measuring device: -150 … 150 mm / -5.9 … 5.9"
  • ** N.B. The mounting plate ADP-UNI accessory must be ordered for internal load cell force gauges ***

Universal Testing Machine PCE-MTS500-DFG N 5K FD 300 KIT incl. Force Gauge
₹580,008.00
Price excl. VAT &. delivery
2 year Warranty

Our universal testing machine can be coupled and operated in a wide variety of versions with our force gauges, the PCE series. The motorized universal testing machine lets you carry out almost all of your compression and tensile force applications with repeatability. The use of the universal testing machine offers the operator the most precise equality of test bench and sample.

  • Force range: max. 5000 N / 500 kg / 1100 lbs
  • Travel: max. 300 mm / 11.8"
  • Feed speed: 30 … 230 mm/min / 1.18 … 9.05 in/min
  • Manual or automatic procedure
  • incl. length measuring device: -150 … 150 mm / -5.9 … 5.9"
  • incl. software
  • incl. force gauge PCE-DFG N 5K (0 … 5000 N)
  • ** N.B. The mounting plate ADP-UNI accessory must be ordered for internal load cell force gauges ***

Ultrasonic Thickness Tester PCE-TG 300-HT5-ICA incl. ISO calibration certificate
₹195,955.00
Price excl. VAT &. delivery
2 year Warranty
ISO Calibration

The PCE-TG 300-HT5 is an ultrasonic thickness tester for measuring wall thickness. In general, the wall thicknesses of all homogeneous materials can be measured with the ultrasonic thickness tester. Wall thicknesses under a coating can also be measured with the ultrasonic thickness tester.

  • Measuring range: 1 … 600 mm / 0.039 … 23.62" (steel)
  • Diameter: 12mm / 0.47"
  • Minimum diameter of pipes: 30 mm / 1.18"
  • Frequency: 5MHz
  • Bluetooth
  • incl. ISO calibration certificate
