Weighbridge

PCE-SW 1500N is a portable battery-powered industrial weighbridge or pallet scale featuring two heavy-duty parallel weighing beams made of lacquered steel that can be positioned up to 4 m / 13 ft apart. Thus, the adjustable width accommodates multiple pallet, box and container sizes. In addition, the scale's stainless-steel-encased display can be placed up to 5 m / 16 ft away from the weighing beams, allowing for wall mounting.

• Weighing capacity: 1500 kg / 3306 lb (=1.65 T)
• Weighing units: kilograms (kg) or pounds (lbs)
• Resolution: 0.5 kg
• Accuracy: ± 2 kg
• Bi-directional RS-232 interface

PCE-SW 3000N is a portable battery-powered industrial weighbridge or pallet scale featuring two heavy-duty parallel weighing beams made of lacquered steel that can be positioned up to 4 m / 13 ft apart. Thus, the adjustable width accommodates multiple pallet, box and container sizes. In addition, the scale's stainless-steel-encased display can be placed up to 5 m / 16 ft away from the weighing beams, allowing for wall mounting.

• Weighing capacity: 3000 kg / 6613 lb (=3.3 T)
• Weighing units: kilograms (kg) or pounds (lbs)
• Resolution: 1 kg
• Accuracy: ± 4 kg
• Bi-directional RS-232 interface

The weighbridge PCE-RS 2000 is designed for stationary use. The robust construction makes this weighbridge particularly well suited for weighing large objects. The weighbridge is made of painted steel.

• Weighing capacity: 2000 kg
• Resolution: 0.5 kg
• Bidirectional RS-232 interface
• Analog output 4 … 20 mA optional

PCE-SW 5000N is a portable battery-powered industrial weighbridge or pallet scale featuring two heavy-duty parallel weighing beams made of lacquered steel that can be positioned up to 4 m / 13 ft apart. Thus, the adjustable width accommodates multiple pallet, box and container sizes. In addition, the weighbridge's stainless-steel-encased display can be placed up to 4 m / 13 ft away from the weighing beams, allowing for wall mounting.

• Weighing capacity: 5000 kg / 11023 lb (=5.5 T)
• Weighing units: kilograms (kg) or pounds (lbs)
• Resolution: 2 kg
• Accuracy: ± 8 kg
• Bi-directional RS-232 interface

The weighbridge is a verifiable weighing balance that is intended for flexible use. Due to the flexibly movable weighing beam (4 m), the weighbridge is well suited for weighing large objects, and non-standard pallet sizes can also be weighed quickly and conveniently.

• Weighing range : 300 kg
• Readability: 0.1 kg
• Calibration value: 0.1 kg
• Verifiable M III

The weighbridge is a verifiable weighing balance that is intended for flexible use. Due to the flexibly movable weighing beam (4 m), the weighbridge is well suited for weighing large objects, and non-standard pallet sizes can also be weighed quickly and conveniently.

• Weighing range : 600 kg
• Readability: 0.2 kg
• Calibration value: 0.2 kg
• Verifiable M III

The weighbridge is a verifiable, calibrated U-shaped pallet scale intended for mobile use. The dimensions of the calibrated weighbridge are the standard EU size (1200 x 800 mm).

• Weighing range: 0 … 1500 kg
• Readability: 0.5 kg
• Calibration value: 0.5 kg
• Verifiable M III

The weighbridge is a verifiable weighing balance that is intended for flexible use. Due to the flexibly movable weighing beam (4 m), the weighbridge is well suited for weighing large objects, and non-standard pallet sizes can also be weighed quickly and conveniently.

• Weighing range : 3000 kg
• Readability: 1 kg
• Calibration value: 1 kg
• Verifiable M III

The weighbridge is supplied calibrated and is intended for stationary use with its solid construction. Due to the robust design and the large platform, this calibrated weighing platform is particularly suitable for weighing large objects.

• Weighing range : 1500 kg
• Readability : 0.5 kg
• Taring range: over the entire weighing range
• Includes initial verification
• Calibratable M III
